PPGI Steel Coil Prepainted Galvanised Steel Coil / Sheet With Advanced Coating Technology

PPGI Steel Coil Prepainted Galvanised Steel Coil / Sheet With Advanced Coating Technology

Product Details:

Place of Origin: CHINA
Brand Name: PPGI--HUIYI
Certification: SGS,BV,ISO
Model Number: G550,G450,G400,CGCC,CGLCC,CGCH,CGLCH,DX51D

Payment & Shipping Terms:

Minimum Order Quantity: 25 tons
Price: USD/MT
Packaging Details: export packing with waterproof paper, PE Film,Iron sheet
Delivery Time: 20-35days
Supply Ability: 5000 tons per month
Get Best Price Contact Now

Detail Information

Product Name: Prepainted Galvanised Steel Coil Type: Coil,plate,corrugated
Coil Weight: 4-20T Back Paint Coating: 5-15um
Color: Ral Colors Front Paint Coating: 15-35um
Thickness: 0.12-2.0mm Zinc Coating: Z30-Z275g/m2
Paint Brand: PPG,AKZO,NIPPON,DULUX Width: 914mm/1000mm/1200mm/1219mm Or Other Required Width
Highlight:

Prepainted Galvanised Steel Coil

,

PPGI Steel Coil

,

Back Paint Coating PPGI Steel Coil

Product Description

Introduction of PPGI steel coil :

PPGI steel coil are coated with galvanized strip or aluminized zine silicon on a continuous set. After surface pretreatment (degreasing and learning), a layer or multi layer liquid coating is coated with roll coating.



The plate is coated by baking and cooling. Because coatings can have different colors, it is customary to use coated steel plates as coloured coated steel plates. The products obtained by coating organic coatings on hot-dip galvanized steel or aluminum zinc silicon are hot dip galvanized color coated boards or aluminized zinc silicon color coated boards.




In addition to zinc's protective properties, the organic coating on the surface provides insulation and rust prevention, offering a longer service life compared to hot-dip galvanized steel sheets.



Pre-painted steel coils (color-coated steel coils) combine the mechanical strength of steel with excellent formability, along with superior decorative appeal and corrosion resistance.



Thanks to their strong interlayer adhesion, color-coated plates retain their vibrant appearance for extended periods. As a result, they are widely used in architectural exteriors and consumer electronics, enhancing both durability and a sleek, sophisticated finish.





            PPGI Steel Coil Prepainted Galvanised Steel Coil / Sheet With Advanced Coating Technology 0





Specification of PPGI steel coil :



Standard: JIS G3312-1998, ASTM A755, GB/T12754-2006 Zinc Coating : Min Single Side --- 30g/sqm
Grade: SPCC,SPCD,SPCE,DX51/52/53/54D+Z,Q195/215/235 And Etc Paint Coating  : front 20-35um,back 5-15um
Base Metal: Cold Rolled Steel/Galvanized Steel/Galvalume Steel Paint Brand:Akzo Nobel,Nippon,PPG
Material Thickness: Normally 0.12-2.0mm Coil ID:508MM/610MM
Width: 30-1500mm(Mainly in 914mm,1000mm,1219mm and 1250mm) Surface Finished Color: According To RAL Standard
Coating: PE/PVDF/SMP Packing Condition: Seaworthy



Characteristics of PPGI steel coil :



Color-coated steel offers excellent decorativeness, bendability, corrosion resistance, coating adhesion, and color fastness. As an eco-friendly and cost-effective alternative to wood panels in construction, it provides advantages such as easy installation, energy efficiency, and stain resistance.



Textured color-coated steel sheets further enhance scratch resistance, ensuring long-lasting durability. Available in a wide range of colors, these sheets are manufactured with consistent quality and can be economically mass-produced to meet diverse industrial needs.







PPGI steel coil  Application:



1. Carrying Trade



Container , Exterior Decoration Of Auto And Train, Clapboard, lsolation Board



2. Buildings And Constructions



Corrugated Roof And Wall , Workshop, Warehouse, Roller Shutter Door , Rainwater, Drainage Pipe



3. Electrical Appliance



Air Conditioning , Refrigerator, Washer, Switch Cabinet, Micro-wave Oven, Bread Maker , Instrument Cabinate



4. Furniture



Book Shelf , Central Heating Slice, Lampshade



5. Others



Instrument Panel , Writing Panel, Garbage Can, Timekeeper, Typewriter,  Weight Sensor, Billboard ,Photographic Equipment



PPGI Steel Coil Prepainted Galvanised Steel Coil / Sheet With Advanced Coating Technology 1











































































































































FAQ:



Q:Are you a trading company or a manufacturer?



A:We are one of the biggest and professional manufacturer in China. Our products are hot-sale due to our superior quality, competitive price and the best after-sales service.



Q:How about the MOQ?



A:Generally, the MOQ can be placed depending on different products.



Q:How about the sample if I need?



A:The sample is free of charge



Q:Do you have English Mill Test Certificates?



A:Yes, we can provide MTC attached to your documents.



Q:What is shipment terms?



A: 1. Container ship 2. Bulk ship 3. Train



Q:How about the delivery time?


A:About 10-25 days after receiving the deposit. Certainly, the detail will be confirmed by the quantity and the different products.
