Prepainted GI Steel Coil / Color Coated 0.8mm Galvanized Steel Sheet In Coil
Product Details:
| Place of Origin: | China |
| Brand Name: | HUIYI-PPGL |
| Certification: | ASTM, AISI, GB, JIS, DIN, EN |
| Model Number: | G550 , G450 , G300,DX51D+Z,DX52D+Z, SGCC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 22tons each thickness |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Standard exporting package , wrapped with waterproof paper. Then after fully wrapped with high density PE film. Then after fully covered with iron sheet with metal edge protectors, strapped with metal bands, min 4 bands horizontal, min 3 bands vertical. |
| Delivery Time: | 15-35days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 5000 tons per month |
|
Detail Information |
|||
| Product Name: | PPGI Steel Coil | Stansard: | AISI,ASTM,BS,DIN,GB,JIS |
|---|---|---|---|
| Technique: | Cold Rolled | Thickness: | 0.3-2.0mm |
| Width: | 914/1000/1219/1220/1200/1250mm | Zinc Coating: | Z80-Z120 |
| Film Thickness: | Top Side:15-25μm, Back Side：7-8μm | Application: | Roofing,Construction,Structure |
| Highlight: | Cold Rolled Prepainted GI Steel Coil,0.8mm Galvanized Steel Sheet In Coil,Prepainted Galvanized Sheet Coil |
||
Product Description
Prepainted GI Steel Coil / Color Coated 0.8mm Galvanized Steel Sheet In Coil
The PPGI steel coil is available in a wide range of colors and finishes, and it can be custom produced to meet specific design and application requirements. The coating process involves cleaning the steel surface, applying a primer, and then adding multiple layers of paint or resin. The coating thickness can be adjusted as per the desired protection level and aesthetic preference.
Technical Parameters:
| Product name | prepainted steel coil |
| Stansard | AISI,ASTM,BS,DIN,GB,JIS |
| Material Grade | SGCC/CGCC/DX51D+Z |
| Surface Treament | Coated |
| Coating Material | PE,SMP,HDP,PVDF |
| Color | All RAL colors or customers sampels color |
| Top Coating Thickness | 15μm-25μm |
| Back Coated Thickness | 7μm-8μm |
| Thickness | 0.3-2.0mm |
| Width | 600-1500mm |
| Coil ID | 508/610mm |
| Coil Weight | 3-8 tons |
| Packaging | Standard export seaworthy packing |
| Transport | Ocean Shipping |
| Port | Tianjin/Qingdao |
| Delivery Time | 15-40 days after receive deposit |
| Payment | 30% T/T for deposit and the balance against the copy of BL or L/C |
Product Advantages:
1.Good durability and long life compared with galvanized steel coil.
2.Good heat resistance, less discoloration at high temperature than galvanized steel coil.
3.Good thermal reflectivity.
4.Processability and spraying performance similar to galvanized steel coil.
5.Good welding performance.
6.Good performance-price ratio, durable performance and extremely competitive price.
Applications:
PPGI is available in a wide range of colors and finishes, allowing for customization and versatility in various applications. It is commonly used for roofing, wall cladding, garage doors, appliances, and automotive parts.
Packing and Shipping:
PPGI Steel Coil are usually packaged and shipped in coil form, tied with steel strips and wrapped with plastic film to protect from moisture. The steel coil can then be loaded onto trucks and vessels for transportation.
FAQ:
A1: PPGI Steel Coil is a pre-painted galvanized iron coil, which has the substrate of cold-rolled steel coil and galvanized steel coil, and then coated with an organic coating on the top.
A2: PPGI Steel Coil is strong, durable, corrosion resistant and has a longer service life than other types of steel products. It also has good insulation properties, beautiful colors and excellent decorative properties.
A3: PPGI Steel Coil is widely used in construction, household appliances, transportation, light industry, office furniture, machinery and other industries.
A4: The size of PPGI Steel Coil can be customized according to the requirements of customers.
A5: Generally, the payment term for PPGI Steel Coil is T/T or L/C.
