Cold Rolled Self Cleaning PPGI Steel Coil Galvanized Coated
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | PPGI---HUIYI |
| Certification: | SGS,ISO,BV |
| Model Number: | CGCC,CGLCC, CGCH , G550,G400,G450,DX51D |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25 tons |
|---|---|
| Price: | USD/MT |
| Packaging Details: | Standard exporting package.wrapped with waterproof paper，high density PE film，iron sheet with metal edge protectors, strapped with metal bands, min 4 bands horizontal, min 3 bands vertical |
| Delivery Time: | 20-35days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 5000 tons per month |
|
Detail Information |
|||
| Product Name: | PE / PVDF / SMP , JIS G3322 , Color Coated Coil / Plat | Surface Treatment: | Coated，galvanised |
|---|---|---|---|
| Thickness: | 0.12-2.0mm | Width: | Under 1500mm |
| Material: | GI,GL,SS Steel，Aluminium | Application: | Roofing ，decoration |
| Coil ID: | 508MM,610MM | Coil Weight: | Based On Customers‘requirements |
| Highlight: | Cold Rolled PPGI Galvanized Steel Coil,Self Cleaning PPGI Steel Sheet,Galvanized Coated PPGI Colour Coated Sheet |
||
Product Description
ISO 0.12mm 1250mm Self Cleaning Galvanised Steel Sheet In Coil
PPGI steel coil introduction :
PPGI steel coil is a new type of building material that has rapidly developed in the world in the past 30 years .PPGI steel coil is refined by chemical pretreatment ,primary coating and other processes on a continuous unit .The coating quality is much more uniform , stable and ideal than that of single-piece spraying or brushing on the formed metal surface . The R & D and production of the coating system to fill the domestic PVDF coating system of thick blanks, is widely used in high-end decontamination sandwich panels, corrugated board, curtain wall, ceiling and veneer direct use of high-end indoor and outdoor decoration fields.Our self-cleaning technology is to give the film a strong anti-pollution performance and hydrophilic properties, which can be used to wash the rain and easy to place pollutants, so that the film to clean, to protect the film from some pollution Destruction of objects.
Application range of PPGI steel coil :
Production of roofing,wall panel,garage,barrier,shutter,frame of window,air-condition system covering,solar heating,electrical unit,refrigerated wagon and so on
Specification of prepainted Galvanised steel :
| Standard : | JIS G3312-1998 , ASTM A755 , GB / T12754 - 2006 |
| Grade : | SPCC , SPCD , SPCE , DX51 / 52 / 53 / 54D + Z , Q195 / 215 / 235 And Etc |
| Base Metal : | Cold Rolled Steel / Galvanized Steel / Galvalume Steel |
| Material Thickness : | Normally 0.15 -1.5 mm |
| Width : | 30 - 1500 mm ( Mainly in 914 mm ,1000 mm , 1219 mm and 1250 mm ) |
| Coating : | PE / PVDF / SMP |
| Coating Thickness : | Min. Single Side - 50 g / sqm Max. Single Side - 275 g / sqm |
| Top Painting : | 15 - 35 micrometer |
| Back Painting : | 5 - 25 micrometer |
| Surface Finished Color : | According To RAL Standard |
| Packing Condition : | Seaworthy |
Characteristics :
Color Coated Steel Feature Excellent Decorativeness , Bendability , Corrosion Resistance, Coating Adhesion And Color Fastness .
They Are Ideal Substitutes For Wood Panels In The Construction Industry Because Of Their Good Economic Features Such As Convenient Installation , Conservation Of Energy And Resistance To Contamination .
Color Steel Sheets With Surface Texturing On The Surface Has Extremely Superb Anti - Scratch Qualities , Can Be Produced In Various Colors , And Has Credible Quality And Can Be Mass - Produced Economically.
Product Application of prepainted galvalume steel :
| Buildings And Constructions | Workshop , Warehouse , Corrugated Roof And Wall , Rainwater , Drainage Pipe , Roller Shutter Door |
| Electrical Appliance | Refrigerator , Washer , Switch Cabinet , Instrument Cabinet , Air Conditioning , Micro - wave Oven , Bread Maker |
| Furniture | Central Heating Slice , Lampshade , Book Shelf |
| Carrying Trade | Exterior Decoration Of Auto And Train , Clapboard , Container , Insulation Board |
| Others | Writing Panel , Garbage Can , Billboard , Timekeeper , Typewriter , Instrument Panel , Weight Sensor , Photographic Equipment |
