JIS G3322 CGCC 0.12mm PPGI Steel Coil Under 1500mm

JIS G3322 CGCC 0.12mm PPGI Steel Coil Under 1500mm

Product Details:

Place of Origin: CHINA
Brand Name: PPGI---HUIYI
Certification: SGS,ISO,BV
Model Number: CGCC,CGLCC, CGCH , G550,G400,G450,DX51D

Payment & Shipping Terms:

Minimum Order Quantity: 25 tons
Price: USD/MT
Packaging Details: Standard exporting package.wrapped with waterproof paper,high density PE film,iron sheet with metal edge protectors, strapped with metal bands, min 4 bands horizontal, min 3 bands vertical
Delivery Time: 20-35days
Payment Terms: L/C, D/P, T/T
Supply Ability: 5000 tons per month
Get Best Price Contact Now

Detail Information

Product Name: JIS G3322 , Under 1500mm Width , 0.12-2.0mm Thickness Color Coated Coil / Plat Surface Treatment: Coated,galvanised
Thickness: 0.12-2.0mm Width: Under 1500mm
Material: GI,GL,SS Steel,Aluminium Application: Roofing ,decoration
Coil ID: 508MM,610MM Coil Weight: Based On Customers‘requirements
Highlight:

CGCC PPGI Steel Coil

,

HUIYI 2mm color coated gi sheet

,

HUIYI 0.12mm PPGI Steel Coil

Product Description

JIS G3322 , Under 1500mm Width , 0.12-2.0mm Thickness Color coated coil / plat



Pre - Painted Steel Coil / Color Coated Steel Coil , Produced By Printing Or Baking Paints Onto The Surface Of Cold - Rolled Steel Or GI Or GL Sheets.

Generally, it refers to a product formed by coating (roll coating) a substrate after surface treatment or bonding an organic film and baking, which can be further processed into a final product. It’s called "pre-coated steel plate" and "plastic steel plate" in foreign countries. This product has beautiful colors or patterns when it leaves the factory, so it is also called "color coated steel plate". Color coated steel plate is commonly called in our country and is simply called "color coated plate" or "color plate".

The specifications of the company's main color plate: thickness: 0.15-1.5MM, width: 30-1550MM;the maximum speed of the unit: 150M/MIN. The types of coating layer include polyester, silicon modified polyester, polyurethane, polyvinylidene fluoride, super polyester, epoxy resin, acrylic acid, etc. The production line has the ability to meet the requirements of producing medium and high grade products such as building boards and home appliance plates. This line adopts the production process of two coatings and two curing with the complete procedures. The drying furnace adopts the electric heating direct hot air circulation system.





Specification of prepainted Galvanised steel :



 Standard :   JIS G3312-1998 , ASTM A755 , GB / T12754 - 2006
 Grade :  SPCC , SPCD , SPCE , DX51 / 52 / 53 / 54D + Z , Q195 / 215 / 235 And Etc
Base Metal :  Cold Rolled Steel / Galvanized Steel / Galvalume Steel
Material Thickness :  Normally 0.15 -1.5 mm
Width :  30 - 1500 mm ( Mainly in 914 mm ,1000 mm , 1219 mm and 1250 mm )
Coating :  PE / PVDF / SMP
Coating Thickness :  Min. Single Side - 50 g / sqm Max. Single Side - 275 g / sqm
Top Painting :  15 - 35 micrometer
Back Painting :  5 - 25 micrometer
Surface Finished Color :  According To RAL Standard
Packing Condition : Seaworthy



Characteristics :



Color Coated Steel Feature Excellent Decorativeness , Bendability , Corrosion Resistance, Coating Adhesion And Color Fastness .

They Are Ideal Substitutes For Wood Panels In The Construction Industry Because Of Their Good Economic Features Such As Convenient Installation , Conservation Of Energy And Resistance To Contamination .

Color Steel Sheets With Surface Texturing On The Surface Has Extremely Superb Anti - Scratch Qualities , Can Be Produced In Various Colors , And Has Credible Quality And Can Be Mass - Produced Economically.



Product Application of prepainted galvalume steel :



Buildings And Constructions Workshop , Warehouse , Corrugated Roof And Wall , Rainwater , Drainage Pipe , Roller Shutter Door
Electrical Appliance Refrigerator , Washer , Switch Cabinet , Instrument Cabinet , Air Conditioning , Micro - wave Oven , Bread Maker
Furniture Central Heating Slice , Lampshade , Book Shelf
Carrying Trade Exterior Decoration Of Auto And Train , Clapboard , Container , Insulation Board
Others Writing Panel , Garbage Can , Billboard , Timekeeper , Typewriter , Instrument Panel , Weight Sensor , Photographic Equipment
