Prepainted Galvanized Sheet Metal Coils Z30 Zinc Coated
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | PPGI---HUIYI |
| Certification: | SGS,BV,ISO-9001 |
| Model Number: | SGCC,CGCC,SGLCC,CGLCC,GCCH,SGCH,G550,G450,G400,G300 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25 TONS |
|---|---|
| Price: | Deponds on customers’requirements |
| Packaging Details: | Standard exporting package. |
| Delivery Time: | 25-35days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 3000 tons per month |
|
Detail Information |
|||
| Product Name: | Z30-Z275 Zinc Coating Al-Mg-Mn Prepainted Galvanised Steel Coil | Type: | Steel Coil,steel Coil/steel Sheet |
|---|---|---|---|
| Grade: | SGCC,CGCC,DX51D,CGLCC | Zinc Coating: | 30-275g/m2,AZ150 |
| Surface Treatment: | Coated,Galvanized,Printing / Matte | Coil ID: | 508MM / 610MM |
| Front Paint Coating: | 15-35um | Back Paint Coating: | 5-25um |
| Highlight: | Z275 galvanized sheet metal coils,HUIYI CGLCC ppgi color coated sheets,HUIYI Z30 galvanized sheet metal coils |
||
Product Description
Z30-Z275 Zinc Coating Al-Mg-Mn Prepainted Galvanised Steel Coil
Introduction:
It is made by taking hot galvanized sheet and zinc-iron alloy hot galvanized sheet as the substrate through surface pretreatment, coating one or more layers of liquid coating by roll coating, baking and cooling. With GI as base metal,after pretreatment(degrease and chemical treatment)and liquid dope with several layers of color,then after firing and cooling,finally the plate steel is called pre-painted galvanized steel(PPGl).Pre-painted gaIvanized steeI is good capable of decoration,molding,corrosion resistance.
Galvanized Sheet:
Hot galvanized sheet and alloying galvanized sheet have excellent performance, ideal combination property including corrosion resistance, formation and coating, and are mainly used for building, automobiles, metallurgy, and electrical equipment. Galvanized sheet is mainly used for making roof, door and window, roller shutter door, and suspended skeleton in building industry, vehicle shell, chassis, door, trunk lid, oil tank and fender in auto industry, steel sash blank and color coated sheet substrate in metallurgy industry, and refrigerator base, shell, refrigerating chamber, kitchen equipment and other parts in electrical equipment industry.
Cold Rolled Sheet:
Cold sheet has excellent type and surface quality and mechanical property indexes meeting customer demands. It is widely used for galvanized substrate, home appliances, tubbing, automobile, building, enamel, and other industries.
Hot Rolling Pickling Steel Strip
Number and Mechanical Property
| No. | Tensile test | ||||||
| Yield strength Rel (MPa) |
Tensile strength Rm (MPa) |
Percentage elongation after fracture A% | |||||
| 1.8～＜2.0 | 2.0～＜2.5 | 2.5～＜3.2 | 3.2～＜4.0 | ≥4.0 | |||
| SPHC | ≥270 | ≥29 | ≥30 | ≥31 | ≥32 | ≥32 | |
| SPHD | ≥270 | ≥32 | ≥33 | ≥35 | ≥37 | ≥39 | |
| SPHE | ≥270 | ≥33 | ≥35 | ≥37 | ≥39 | ≥41 | |
| SS330 | ≥205 | 330～430 | ≥26 | ||||
| SS400 | ≥245 | 400～510 | ≥21 | ||||
| SAPH310 | ≥ | ||||||
| SAPH370 | ≥370 | ≥255 | ≥32 | ||||
| SAPH400 | ≥ | ||||||
| SAPH440 | ≥ | ||||||
|
Notes: 1. The tensile test specified value in the table is suitable for longitudinal test piece. 3. Steel strip is delivered in the state of hot rolling.
|
|||||||
PRODUCTION PARAMENTERS
Description : Pre-painted galvanized /galvalume steel coil/sheet
Coil Weight : Standard is 5-8mt, always based on customers’ requirements
Thickness : 0.12mm~3.0mm
Width : 914mm,1000mm,1200mm,1219mm,1250mm,1500mm
PRODUCT APPLICATION
PACKING AND SHIPPING
Standard exporting package.wrapped with waterproof paper.Then after fully wrapped with high density PE film.
Then after fully covered with iron sheet with metal edge protectors, strapped with metal bands, min 4 bands horizontal,
min 3 bands vertical
