Z275 Colour Coated Galvanised Sheets 1250mm CGLCCD
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | PPGL--HUIYI |
| Certification: | SGS,BV,ISO |
| Model Number: | CGCC,CGCH,CGLCC,CGLCH，DX51D,DX52D |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25TONS |
|---|---|
| Price: | USD/MT |
| Packaging Details: | Standard exporting package. waterproof paper， high density PE film，iron sheet with metal edge protectors, strapped with metal bands |
| Delivery Time: | 20-35days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 5000 tons per month |
|
Detail Information |
|||
| Product Name: | Z20-Z275 Zinc Coating Prepainted Galvanised Steel Coil Sheet | Color: | Bright Red , Ses Biue , Light Gray , Orange , Blue , Green , Ral Colors And Etc. |
|---|---|---|---|
| Width: | 600mm-1250mm, 750-1250m..... | Thickness: | 0.12-2.0mm |
| Grade: | SGCC, DX51D, DX51D+AZ, DX51D, CGLCCD | Standard: | GB, ASTM, JIS, AISI, BS |
| Zinc Coating: | Z20-Z275 | Coil ID: | 508mm/610mm |
| Highlight: | Z20 colour coated galvanised sheets,HUIYI Z275 color coated steel sheet,HUIYI 1250mm colour coated galvanised sheets |
||
Product Description
Z20-Z275 Zinc coating prepainted galvanised steel coil sheet
It is made by taking hot galvanized sheet and zinc-iron alloy hot galvanized sheet as the substrate through surface pretreatment, coating one or more layers of liquid coating by roll coating, baking and cooling. The used coatings including polyester, silicon modified polyester, high-durability polyester, polyvinylidene fluoride, epoxy and high corrosion-resisting coating are widely used for building, transport, home appliances, solar energy, furniture, etc. It is mainly used as the side door plate of refrigerators, and shell of DVDs, air conditionings, freezers, and washing machines.The product uses metal ion dissolution of the antibacterial mechanism, in the course of antibacterial agent slowly release metal ions, dissolution of metal ions that can destroy the bacterial cell membrane or cell protoplasm activity of enzyme activity, also has anti-yellow staphylococcus and Escherichia coli Of the role, with high antibacterial efficiency, antibacterial time is long and so on. Antibacterial color plate on Staphylococcus aureus, Escherichia coli and other Gram-negative bacteria rate of 99% or more, the growth of fungi and fungi also significantly inhibited, is to reduce cross-infection and bacterial infection probability of an effective way , Has broad market prospects and huge application potential.
Application:
Such kind of product is mainly used in hospital walls, ceilings, food storage and processing areas, ventilation systems and other facilities, with excellent antibacterial and processing performance.
Product specifications:
| Thickness: | 0.3mm-1.0mm(BMT) |
| Width: | 914mm-1250mm |
| Paint Brand: | AKZO , NIPPON ,PPG , DULLEX ,PE OR PVDF |
| Color: | RAL Scale ,or based on customers‘samples |
| Coil ID: | 508MM / 610MM |
| Zinc Coating: | Z20-Z275 |
| Grade: | CGCC,CGCH,G550,G450,G400,G300 |
| Front Paint Coating: | 15 -35um |
| Back Paint Coating: | 5-20um |
Here comes some roofing sheets specification:
