China PPGL Roofing Color Coated Steel Coils Hot Dipped Galvalume
Product Details:
Place of Origin: | China |
Brand Name: | HuiYi-Prepainted Galvalume Steel Coil |
Certification: | ASTM, JIS, GB, ANBOTEK |
Model Number: | SGLCC,CGLCC,G550 |
Payment & Shipping Terms:
Minimum Order Quantity: | 22MT |
---|---|
Price: | Negotiation |
Packaging Details: | Exporting Packing with 3layers including the waterproof plastic film,Waterproof paper - plastic film-metal wrap. |
Delivery Time: | 15-30 Days |
Payment Terms: | T/T, L/C, D/P |
Supply Ability: | 5000MT/Month |
Detail Information |
|||
Thickness: | 0.12-1.5mm | Width: | 600-1500mm |
---|---|---|---|
Coil Weight: | 3-8 Tons | Color: | RAL Color |
Coil Id: | 508/610mm | Grade: | CGCC,CGCH,G550,DX51D,DX52D,DX53D |
Zinc Coating: | 30-275g/m2 | Surface: | Matt,High Gloss,Color With Two Sides,Wrinkle, Wooden Color,Marble |
Highlight: | Alu-Zinc Coating PPGL Steel Coil,Color Steel Coils PPGL,Galvalume Steel Coil PPGL |
Product Description
Product Description:
Prepainted galvalume is a pre-painted sheet metal made of galvalume Steel (aluminum (55%), zinc (43.40%), and silicon (1.60%)) with an organic paint roller coated on the surface. The double protection of the zinc-aluminum alloy layer and the paint layer protects the steel from corrosion and rust.
Technical Parameters:
Attribute | Details |
---|---|
Product Name | PPGL Steel Coil |
Place of Origin | China |
Surface Treatment | Coated |
Coating Material | PE,SMP,HDP,PVDF |
Yield Strength | 280-560N/mm² |
Width | 600-1500mm |
Top Coating Thickness | 15μm-25μm |
Applications:
Color coated steel coil/sheet (PPGI & PPGL) is widely used in:
- Building
- Roofing
- Container
- Home Appliances, such as the side door plate of refrigerators, car shell, fence.
- Solar Energy
- Furniture
Specifications:
1.Standard:AISI,ASTM, BS, DIN, GB, JIS
2.Grade:Dx51d,G550,S350GD,all according to the customer's request
3.Color: RAL color or according to customer's sample
4.Thickness: 0.12mm-0.4mm, all available
5.Width: customized
6. Length: according to per customer's requirement
7.Coil ID: 508/610mm
8.Coil weight: according to per customer's requirement
9.Alu-zinc coating:40-275 g/m2
10.Film: 15/5 um, or as per customer's requirement
11.Type of coating: PE, HDP, SMP, PVDF
12.Structure of Prepainted Galvalume Steel Coil:
*Topcoat (finishing) which provides color, pleasing appearance and appearance and a barrier film to enhance long-term durability.
*Primer coat to prevent undercutting of paint and enhance corrosion resistance.
*Pretreatment layer applied for good adhesion and to enhance corrosion resistance.
*Base steel sheet.
Packing and Shipping:
Packing:Exporting Packing with 3layers including the waterproof plastic film, Waterproof paper - plastic film-metal wrap.
FAQ:
1. Q: What is the brand name of the Prepainted Galvalume Steel Coil you offer?
A: The brand name of our Prepainted Galvalume Steel Coil is HuiYi-Prepainted Galvalume Steel Coil.
2. Q: Can you provide the model numbers for your HuiYi-Prepainted Galvalume Steel Coil?
A: Yes, the model numbers for our product are SGLCC, CGLCC, and G550.
3.Q: Is PPGL safe to handle?
A: PPGL is generally considered safe to handle when proper safety precautions are followed. However, it is important to avoid prolonged skin contact and inhalation of vapors. Always refer to the Material Safety Data Sheet (MSDS) for specific safety guidelines.
6.Q:How should PPGL be stored?
A: PPGL should be stored in a cool, dry place, away from direct sunlight and heat sources. Containers should be tightly sealed to prevent contamination and moisture absorption.
7. Q:What is the shelf life of PPGL?
A:The shelf life of PPGL typically ranges from 12 to 24 months when stored under recommended conditions. Always check the manufacturer's guidelines for specific shelf life information.
