DC51D PPGL Prepainted Galvalume Steel Coil Color Coated Cold Rolled Coil

DC51D PPGL Prepainted Galvalume Steel Coil Color Coated Cold Rolled Coil

Product Details:

Place of Origin: CHINA
Brand Name: PPGL---HUIYI
Certification: SGS,BV,ISO-9001
Model Number: SGCC,CGCC,SGLCC,CGLCC,GCCH,SGCH,G550,G450,G400,G300

Payment & Shipping Terms:

Minimum Order Quantity: 25 TONS
Price: Deponds on customers’requirements(USD/MT)
Packaging Details: Standard exporting package.
Delivery Time: 25-35days
Payment Terms: L/C, T/T
Supply Ability: 3000 tons per month
Get Best Price Contact Now

Detail Information

Application: Roofing,Building Construction Width: 600mm-1250mm
Length: Customized Technique: Galvanized Steel / Galvalume Steel /Aluminum
Thickness: 0.12MM-1.2MM Zinc Coating: 40g/m2 - 275g/m2
Grade: SGCC,DX51D,CGLCC Standard: GB,ASTM,JIS
Highlight:

Prepainted Galvalume Steel Coil PPGL

,

DC51D Prepainted Galvalume Steel Coil

,

Color Coated Cold Rolled Coil 1.2mm

Product Description

Al-Mg-Mn color plate / Al-Mg-Mn PPGL / Al-Mg-Mn Prepainted Galvalume Steel Coil,CGLCC,CGLCH



Introduction of prepainted galvalume steel coil :



It is made by taking hot galvanized sheet and zinc-iron alloy hot galvanized sheet as the substrate through surface pretreatment, coating one or more layers of liquid coating by roll coating, baking and cooling. The used coatings including polyester, silicon modified polyester, high-durability polyester, polyvinylidene fluoride, epoxy and high corrosion-resisting coating are widely used for building, transport, home appliances, solar energy, furniture, etc. It is mainly used as the side door plate of refrigerators, and shell of DVDs, air conditionings, freezers, and washing machines.



Number and Mechanical Property of prepainted galvalume steel coil :

Products Name
PPGL
Grade
G550, etc
Paint film
Top:15-25um
Back :5-8um
Surface Treatment
Coated/ Prepainted galvanized
Surface coating
PE, SMP, HDP, PVDF
Aluzinc Coating
40g/m2 - 275g/m2
Coil Weight
3-8 Tons
Thickness
0.12MM-1.2MM
Width
600mm-1250mm
Color
All RAL code or as customer's sample
Length
Coil or as customer's request
Packing details
waterproof paper+plastic film+iron packing+bunding or as per customers request.
Delivery time
15-45 days after receiving deposit



Prepainted galvalume steel coil PARAMENTERS



Description  :     Pre-painted galvanized /galvalume steel coil/sheet

Coil Weight  :     Standard is 5-8mt, always based on customers’ requirements

Thickness    :     0.12MM-1.2MM

Width           :     914mm,1000mm,1200mm,1219mm,1250mm,1500mm



Galvanized Sheet:
Hot galvanized sheet and alloying galvanized sheet have excellent performance, ideal combination property including corrosion resistance, formation and coating, and are mainly used for building, automobiles, metallurgy, and electrical equipment. Galvanized sheet is mainly used for making roof, door and window, roller shutter door, and suspended skeleton in building industry, vehicle shell, chassis, door, trunk lid, oil tank and fender in auto industry, steel sash blank and color coated sheet substrate in metallurgy industry, and refrigerator base, shell, refrigerating chamber, kitchen equipment and other parts in electrical equipment industry.



Cold Rolled Sheet:
Cold sheet has excellent type and surface quality and mechanical property indexes meeting customer demands. It is widely used for galvanized substrate, home appliances, tubbing, automobile, building, enamel, and other industries.



Prepainted galvalume steel coil APPLICATION



DC51D PPGL Prepainted Galvalume Steel Coil Color Coated Cold Rolled Coil 0



PACKING AND SHIPPING OF PREPAINTED GALVALUME STEEL COIL :



Standard exporting package.wrapped with waterproof paper.Then after fully wrapped with high density PE film.Then after fully covered with iron sheet with metal edge protectors, strapped with metal bands, min 4 bands horizontal, min 3 bands vertical



DC51D PPGL Prepainted Galvalume Steel Coil Color Coated Cold Rolled Coil 1
