Cold Rolled PPGL Steel Coil S350GD DX53D For Building Exteriors And Electronics

Cold Rolled PPGL Steel Coil S350GD DX53D For Building Exteriors And Electronics

Product Details:

Place of Origin: CHINA
Brand Name: HUIYI
Certification: SGS,BV,ISO9001
Model Number: CGCC,CGCH,G550

Payment & Shipping Terms:

Minimum Order Quantity: 25
Price: Based on actual requirements
Packaging Details: waterproof paper, high density PE film,iron sheet with metal edge protectors, strapped with metal bands, min 4 bands horizontal, min 3 bands vertical
Delivery Time: 20-35days
Payment Terms: L/C, D/P, T/T
Supply Ability: 5000 tons per month
Get Best Price Contact Now

Detail Information

Product Name: PPGL Grade: CGCC,CGLCC,G550
Color: All Ral Colors Surface Treatment: Coated,Galvalnised
Thickness: 0.12-1.5mm Width: 500-1250mm
Coil Weight: 3-5mt, Based On Requirements Type: Corrugated Sheet,flat,coil
Highlight:

Cold Rolled PPGL Steel Coil

,

Electronics PPGL Steel Coil

,

Building Exteriors PPGL Steel Coil

Product Description

Profile of Prepainted galvalume steel coil :



Prepainted steel typically refers to a product that is manufactured by applying a coating—usually through a roll coating process—onto a metal substrate after surface treatment or by bonding an organic film, followed by baking.



These pre-coated metals come in a wide variety of colors and patterns, making them especially suitable for enhancing the appearance of building exteriors and consumer electronic products. Depending on the intended application, various specialized features can be incorporated into the coating, such as resistance to pollutants, anti-bacterial properties, and improved durability.



Cold Rolled PPGL Steel Coil S350GD DX53D For Building Exteriors And Electronics 0





Specification of Prepainted galvalume steel coil :



■ Standard : JIS G3312-1998 , ASTM A755 , GB / T12754 - 2006

■ Grade : SPCC , SPCD , SPCE , DX51 / 52 / 53 / 54D + Z , Q195 / 215 / 235 And Etc

■ Base Metal : Cold Rolled Steel / Galvanized Steel / Galvalume Steel

■ Material Thickness : Normally 0.15 -1.5 mm

■ Width : 30 - 1500 mm ( Mainly in 914 mm ,1000 mm , 1219 mm and 1250 mm )

■ Coating : PE / PVDF / SMP

■ Coating Thickness : Min. Single Side - 50 g / sqm Max. Single Side - 275 g / sqm

■ Top Painting : 13 - 20 micrometer

■ Back Painting : 7 - 10 micrometer

■ Surface Finished Color : According To RAL Standard

■ Packing Condition : Seaworthy





Types of Prepainted galvalume steel coil :



Available Painting
Category of Painting Item Code
Polyester PE
High-durability Polyester HDP
Silicon Modified Polyesters SMP
Polyvinylidene Fluoride PVDF
Easy-cleaning EC
Painting Thickness Top side 10-20±5microns
Bottom side 5-7microns
Back side 5-7microns





Characteristics of Prepainted galvalume steel coil :



Color Coated Steel Feature Excellent Decorativeness , Bendability , Corrosion Resistance, Coating Adhesion And Color Fastness .

They Are Ideal Substitutes For Wood Panels In The Construction Industry Because Of Their Good Economic Features Such As Convenient Installation , Conservation Of Energy And Resistance To Contamination .



Color Steel Sheets With Surface Texturing On The Surface Has Extremely Superb Anti - Scratch Qualities ,Can Be Produced In Various Colors , And Has Credible Quality And Can Be Mass - Produced Economically.





Some building cases of Prepainted galvalume steel coil :



Cold Rolled PPGL Steel Coil S350GD DX53D For Building Exteriors And Electronics 1







FAQ:



Q:Are you a trading company or a manufacturer?

A:We are one of the biggest and professional manufacturer in China. Our products are hot-sale due to our superior quality, competitive price and the best after-sales service.



Q:How about the MOQ?

A:Generally, the MOQ can be placed depending on different products.



Q:How about the sample if I need?

A:The sample is free of charge



Q:Do you have English Mill Test Certificates?

A:Yes, we can provide MTC attached to your documents.



Q:What is shipment terms?

A: 1. Container ship 2. Bulk ship 3. Train



Q:How about the delivery time?
A:About 10-25 days after receiving the deposit. Certainly, the detail will be confirmed by the quantity and the different products.
