Building Material Prepainted Galvalume Steel Coil Top Painting 24 Guage 25um

Building Material Prepainted Galvalume Steel Coil Top Painting 24 Guage 25um

Product Details:

Place of Origin: CHINA
Brand Name: Matte PPGL---HUIYI
Certification: SGS,BV,ISO-9001
Model Number: SGCC,CGCC,SGLCC,CGLCC,GCCH,SGCH,G550,G450,G400,G300

Payment & Shipping Terms:

Minimum Order Quantity: 25 TONS
Price: Deponds on customers’requirements
Packaging Details: Standard exporting package.
Delivery Time: 25-35days
Payment Terms: L/C, T/T
Supply Ability: 3000 tons per month
Get Best Price Contact Now

Detail Information

Type: Steel Coil,steel Coil/steel Sheet Grade: CGCC, SGCC,SGLCC
Zinc Coating: 40-275g/m2 Surface Treatment: RAL/Printed/Matte/Wrinkled/Embossed/Nano
Coil Weight: Standard Is 5-8mt, Always Based On Customers’ Requirements Thickness: 0.1mm-300mm Or As Required
Width: 0.6m-3m Or As Required Product Name: Roofing,CGCC,CGCH,DX51D
Highlight:

Prepainted Steel Coil 24 Guage

,

Prepainted Color Coated Steel Coil

,

Galvalume Pre Painted Coils

Product Description

24 guage black charcoal 25um top painting prepainted Galvalume steel coil using for building material



PREPAINTED GALVALUME STEEL COIL PARAMENTERS:



Product Name
Glavanized Steel Coils/Galvalume/PPGI/PPGL
Material
Q235B,Q195,DX51,SPCC
Length
1-12m or as required
Width
0.6m-3m or as required
Thickness
0.1mm-300mm or as required
Standard
AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Technique
Cold rolled
Surface Treatment
Clean, blasting and painting according to customer requirement
Coatings
Top Coats :5 micron primer + 20 micron colour Back Coat: 5 micron primer – 7 micron primer
Shipment Time
Within 15-20 workdays after receiving deposit or L/C
Export Packing
Waterproof paper, and steel strip packed.
Standard Export Seaworthy Package.Suit for all kinds of transport,or as required
Capacity
300,000 tons/year
MOQ
1container
Free Sample
Send Inquiry to get Free Sample for evaluation



Here comes several frequent-used Prepainted galvalume steel coil products:

  • Color coated roofing sheets
  • Car steel sheets
  • household electric appliances steel sheets



PREPAINTED GALVALUME STEEL COIL  DESCRIPTION:



Building Material Prepainted Galvalume Steel Coil Top Painting 24 Guage 25um 0





PREPAINTED GALVALUME STEEL COIL APPLICATION :



Building Material Prepainted Galvalume Steel Coil Top Painting 24 Guage 25um 1





Type Of prepainted galvalume steel coil Coating:



The coating types currently used for PPGI/PPGL steel coil include PE, PVDF, SMP, acrylic, PVC, etc.

PE

The PE-coated color-coated steel sheet is easy to be processed and formed because of its good adhesion, and the price is relatively cheap. But the other degree of UV resistance and chalking resistance is relatively low. PE color coated steel can be used for the roof of ordinary civil buildings.

SMP

SMP steel plate has better durability, and the cost is higher than the PE coating. Silicone is not as good as PE in terms of adhesion and processing formability to materials,

High Durable Polyester (HDP)

It is better than ordinary SMP coatings, and its outdoor weather resistance reaches 16 years. Its flexibility and weather resistance are higher.

PVC

PVC coating has nice anti-chemical and anti-water, and the coasting is relatively thick, which can well protect the substrate.

The PVC coating is rarely used because they pollute the environment.

PVDF

PVDF coatings have great color retention and corrosion resistance. Among the PPGI sheet coating for construction, it is the highest grade.

Acrylic

The comprehensive performance is good, the price is expensive, and it is only used in specific fields (such as containers).



Coating primer Top paint coating Service life(years)
1) Epoxy primer, good adhesion, water resistance, alkali resistance, chemical corrosion resistance, poor single toughness.
2) Polyester primer, good adhesion, good flexibility, sensitive to humid environment, chemical resistance is not as good as epoxy primer.
3) Acrylic primer, good adhesion, good toughness and high pretreatment requirements.
4) polyurethane primer, chemical resistance, abrasion resistance, durability, toughness
1) Polyester resin, good adhesion, molding and outdoor durability. 8-10
2) Silicon Modified Polyester (SMP) 10-15
3) High weather resistant polyester (HDP) 12-15
4) Polyvinyl fluoride (PVC) 12-15
5) Polyvinylidene fluoride/fluorocarbon (PVDF) It has good formability and color retention, good outdoor durability and powder resistance, solvent resistance, limited color and high price. 12-20



Coating Performance Comparison Table:



Category Hardness Bend Corrosion resistance Weather resistance Cost Coating thickness requirements
/um
Polyester excellent good good good excellent 20
Acrylic excellent general good good inferior 20
Silicon modified polyester good general good excellent good 20
PVC sol general excellent excellent good inferior 200
PVDF general excellent excellent excellent inferior 25
HDP good excellent good excellent good 20



PACKING AND SHIPPING OF PREPAINTED GALVALUME STEEL COIL :



Standard exporting package.wrapped with waterproof paper.Then after fully wrapped with high density PE film.Then after fully covered with iron sheet with metal edge protectors, strapped with metal bands, min 4 bands horizontal, min 3 bands vertical





Building Material Prepainted Galvalume Steel Coil Top Painting 24 Guage 25um 2



Query:



1. How about your Payment term?



A: We can do 20% TT as advanced,balance against scan copy of BL before arriving at destination port.



Or 100% irrevocable LC at sight





2. How about your quality?



A: We have experienced inspector to check each order before production,if can not reach customer's



quirements,we won't export to our clients.



3. How about your relationship with your clients?



A: We not only treat our clients as partners,but also friends.We care much about longterm ship,but not one



time business.If you do business with us , you can completely belive us as a friend.



4. How about your experience?



A: We have exported steel products more than 6years, know all kinds of steel products very well.We can always grasp the market and suggest our clients to order at the appropriate time.
