20um Front Paint Building Galvalume Coil Stock For roof profile
Product Details:
| Place of Origin: | China |
| Brand Name: | PPGL&PPGI--HUIYI |
| Certification: | SGS,BV,ISO |
| Model Number: | CGCC,CGCH,CGLCC,CGLCH,G350,G400... |
Payment & Shipping Terms:
| Minimum Order Quantity: | 20 tons each size |
|---|---|
| Price: | based on actual requirements |
| Packaging Details: | Standard exporting package. |
| Delivery Time: | 20-35days deponds on qty |
| Payment Terms: | L/C, T/T, D/P |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Product Name: | Building Material | Standard: | ASTM,AISI,DIN,GB |
|---|---|---|---|
| Thickness: | 0.12-2.0mm | Width: | 600-1500mm |
| Zinc Coating: | AZ30-AZ270 G/M2 | Shape: | Rolled, Coil, Flat，corrugated |
| Paint Coating: | 15-30um | Coil ID: | 508MM / 610MM |
| Highlight: | 20um paint galvalume coil stock,front paint galvalume coil stock,20um prepainted galvalume |
||
Product Description
20um front paint coating Building material PPGL steel coil DX51D
Specification of PPGL steel coil :
| Name | PPGL steel Coil |
| Thickness | 0.12-2.00mm |
| Width | 600-1500mm |
| Single Weight | 3-8MT |
| Zinc Coating | 30-270g/m2 |
| Steel Gardes | TDC51D2, TDC51D+AZ, TDC51D, GR. B, SPCC, SPHC, DX51D, ect. |
| Standard | AISI, GB, JIS |
| Top Paint | 20um |
| Back Paint | 7um |
| Packing | Wrapped by plastic film and waterproof paper, and then fastened on wooden pallet. |
| Or as you request. | |
| Used | Building material, roof, profile, pipe making, furniture making, etc. |
| Supply Ability | 50000MT per month |
| Content | Performance of PE Coating | Performance of PVDF Coating |
| Color Difference | ∆E ≤ 2.0 | ∆E ≤ 1.5 |
| Gloss Difference | ≤5 | ≤5 |
| T-bend | ≤3T | ≤3T |
| Adhesion Grade | 0 | 0 |
| Impact | ≥20kg.cm | ≥50kg.cm |
| Solvent Resistance | 200 times no break | 200 times no break |
| Acidity Resistance | 5％ HCL 24hrs no change | 5％ HCL 24hrs no change |
| Alkali Resistance | 5％ NaOH 24hrs no change color | 5％ NaOH 24hrs no change color |
| Salt Spray Resistance | 720hrs ≤Grade le | 720hrs ≤Grade le |
| Abrasion Resistance | ≥5L/μm | ≥5L/μm |
PPGL steel coil introduction :
Wooden PPGL steel coil is one of the color coated steel. which are extensive used in the roofing metal, outer wall , furniture and other fields in recent years because of its superior surface texture. Replacing wood with steel, can rnot only reduce cost ,but also protect environment.
Here comes some common sizes of PPGL steel coil we export as below:
| SHANGHAI HUIYI INTERNATIONAL CO.,LTD | ||||||
| Room 710,No.188,ChangYi Road,Baoshan District,Shanghai,China. | ||||||
| WOODEN PPGL EXPORTING SIZES | ||||||
| Size | Zinc Coating | Paint coating | Color | Paint Brand | Application | Export Countries |
| 0.18x914 | AZ30-AZ60 | 15-20um |
white,red,blue,green, grey,yellow,brown,ral colors and etc |
Akzo nobel ,Nippon,Dulux,PPG, wanbo,zhengniang, wente and etc |
Roofing metal,roller shutter doors,cold storage door cold bed,warehouse,factory, household electrical appliances and etc. |
Singapore,Malaysia, Thailand,Brunei, Dubai, The Philippines, Ukraine |
| 0.20x914 | AZ30-AZ60 | 15-20um | ||||
| 0.22x914 | AZ30-AZ60 | 15-20um | ||||
| 0.28x914 | AZ30-AZ60 | 15-20um | ||||
| 0.30x914 | AZ30-AZ60 | 15-20um | ||||
| 0.32x914 | AZ30-AZ60 | 15-25um | ||||
| 0.36x914 | AZ30-AZ60 | 15-25um | ||||
| 0.38x914 | AZ60-AZ80 | 15-25um | ||||
| 0.40x914 | AZ60-AZ80 | 15-25um | ||||
| 0.46x914 | AZ60-AZ80 | 15-25um | ||||
| 0.47x914 | AZ60-AZ80 | 15-25um | ||||
| 0.40x1220 | AZ60-AZ150 | 20-30um | ||||
| 0.48x1220 | AZ60-AZ150 | 20-30um | ||||
| 0.50x1220 | AZ60-AZ150 | 20-30um | ||||
| 0.54x1220 | AZ60-AZ150 | 20-30um | ||||
| 0.60x1220 | AZ60-AZ150 | 20-30um | ||||
| 0.80x1220 | AZ80-AZ150 | 20-30um | ||||
| 1.00x1220 | AZ80-AZ150 | 20-30um | ||||
PPGL steel coil APPLICATION :
PACKING AND SHIPPING of PPGL steel coil :
Standard exporting package.wrapped with waterproof paper.Then after fully wrapped with high density PE film.Then after fully covered with iron sheet with metal edge protectors, strapped with metal bands, min 4 bands horizontal, min 3 bands vertical.
Query:
1. How about your Payment term?
A: We can do 20% TT as advanced,balance against scan copy of BL before arriving at destination port.
Or 100% irrevocable LC at sight
2. How about your quality?
A: We have experienced inspector to check each order before production,if can not reach customer's
quirements,we won't export to our clients.
3. How about your relationship with your clients?
A: We not only treat our clients as partners,but also friends.We care much about longterm ship,but not one
time business.If you do business with us , you can completely belive us as a friend.
4. How about your experience?
A: We have exported steel products more than 6years, know all kinds of steel products very well.We can
always grasp the market and suggest our clients to order at the appropriate time.
