0.12mm Thickness  CGCH Grade Ral Color  Prepainted Galvalume Steel PPGL Steel Coil

0.12mm Thickness CGCH Grade Ral Color Prepainted Galvalume Steel PPGL Steel Coil

Product Details:

Place of Origin: China
Brand Name: HUIYI-PPGL
Certification: SGS,BV,ISO9001
Model Number: SPCC , SPCD , SPCE , DX51 / 52 / 53 / 54D + Z Q195 / 215 / 235 And etc

Payment & Shipping Terms:

Minimum Order Quantity: 25 tons for each size
Price: based on market
Packaging Details: Export packing
Delivery Time: 25-40days for each order depends on Qty
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 50000 tons per year
Get Best Price Contact Now

Detail Information

Product Name: 0.12mm Thikcness 914mm Width Surface Treatment: Painted
Paint Brand: Akzo Nobel Front Paint Coating: 15-35um
Back Paint Coating: 5-15um Thickness: 0.12-2.0mm
Grade: CGCC,CGCH,CGLCC,CGLCH Coil Weight: 3-5mt,normally Based On Customer‘s Requirements
Width: 914/1219/1000mm,based On Customer‘s Requirements Color: White,Green,Ral Color Or Customer‘s Requirements
Highlight:

CGCH Grade Prepainted Galvalume Steel

,

Ral color PPGL Steel Coil

,

Aesthetic PPGL Steel Coil

Product Description

0.12mm Pre-Painted Galvalume / PPGL  Steel coil CGCH Grade 914mm Width



PPGL Steel Coil introduction :



PPGL steel coil is pre-painted galvalume steel, also known as Aluzinc steel. The PPGL steel coil uses the cold-rolled steel sheet as a substrate and solidified by 55% aluminum, 43.4% zinc and 1.6% silicon at 600 °C. It combines the physical protection and high durability of aluminum and the electrochemical protection of zinc. It is also called aluzinc steel coil.Pre-painted coils are produced by coating a layer of paint on the surface of cold rolled,galvanized or galvalume coils. Aesthetic appeal and durability are the key features of color coated steel coils.A wide selection of colors is available to the customer and paints designed to meet specific end use could be specified.Our PPGL steel coil are suitable for direct interior as well as exterior application, sandwich panels and so on.PPGL Steel Coil are normally used in roofing material in many foreign contries now,especially in south east asia contries.



PPGL steel coil specifications :



Grade CGCC,CGCH,G550,DX51D,DX52D,DX53D
Thickness 0.12-4.0mm
Width 600-1500mm
Zinc Coating Z40-600 g/m2
Coating Thickness Top-15-35, Back 5-15
Color RAL Color
Surface Matt,High gloss,Color with two sides,Wrinkle,
Wooden color,Marble
Paint Brand Nippon Akzo Nobel Kcc
Coil Weight 2-5tons
Coil ID 508/610 mm



Here comes some buildings that used our PPGL steel coil in Brunei,Malaysia,Thailand...as below.



0.12mm Thickness  CGCH Grade Ral Color  Prepainted Galvalume Steel PPGL Steel Coil 0

0.12mm Thickness  CGCH Grade Ral Color  Prepainted Galvalume Steel PPGL Steel Coil 1





Company profile :



SHANGHAI HUIYI INTERNATIONAL CO.,LTD is a manufacturing company dealing with all kninds of steel products and construction materials.We build long term relationship with many factories in China since our team has dealt with trading business for many years.Our main products are galvanized steel,galvalume steel,pre-painted galvanized steel,pre-painted galvalume steel, corrugated steel,cold roll steel,hot roll steel,angle bar,C channel,Aluminum bubble foil,fiber cement....





FAQ:



Q:Are you a trading company or a manufacturer?

A:We are one of professional manufacturer and supplier in China. Our products are hot-sale due to our superior quality, competitive price and the best after-sales service.



Q:How about the MOQ?

A:Generally, the MOQ is one container .



Q:How about the sample if I need?

A:The sample is free of charge.
