Product Details:

Place of Origin: China
Brand Name: HUIYI
Certification: SGS,BV,ISO9001
Model Number: SPCC , SPCD , SPCE , DX51 / 52 / 53 / 54D + Z Q195 / 215 / 235 And etc

Payment & Shipping Terms:

Minimum Order Quantity: 25 tons each thickness
Price: negotiated
Packaging Details: Standard exporting package.wrapped with waterproof paper.Then high density PE film.Then after fully covered with iron sheet
Delivery Time: 20-35days
Payment Terms: L/C, T/T
Supply Ability: 50000 tons per year
Get Best Price Contact Now

Detail Information

Name: ISO9001 Color Coated Composite Board Series,G550 Color: Red,Green,Blue,Grey,White,Brown,Black,Yellow,Maroon,Orange ,etc.
Paint Brand: Akzo Nobel,Dulux,Nippon,PPG,Local Front Paint Coating: 11-35um
Back Paint Coating: 5-20um AL-ZN Coating: AZ30-AZ150
Corrugated Width: 680mm Or Other Required Size Thickness: 0.12--1.2mm
Coil ID: 508/610mm Surface Treatment: Coated, Galvanized, Printing ,galvalume
Application: Roofing, Transportation, Building Construction, Boiler Plate Standard: GB, ASTM, JIS, AISI, BS
Highlight:

G550 Color Coated Steel Coil

,

Galvanized Color Coated Steel Coil

,

Coated Prepainted Galvalume Steel Coil

Product Description

ISO9001 Color coated Composite board series Prepainted galvalume steel coil,G550



Introduction of prepainted galvalume steel coil :



Prepainted galvalume steel coil is an innovative product by combining the strength of steel with the anti-corrosive capabilities of coatings. It is short for pre-painted galvalume steel coil, which uses aluminum-galvanized steel sheet (55% aluminium, 43% zinc and 1.6% silicon) as base metal. The material is exceptionally resistant to corrosion. It can also withstand to high temperature up to 315 degrees. PPGL coils are used in a wide variety of applications such as roofing & cladding, doors and windows, fencing, lighting, internal partition, ceiling, vehicle manufacturing industry, furniture, home appliance, and shipbuilding industry. Wanzhi Steel offers PPGL coil with width of 600-1,250 mm, and the thickness of 0.12-1.2 mm. There are also various colors and patterns to choose from.



MAIN PARAMETERS of prepainted galvalume steel coil :



Thickness: 0.12mm-1.2mm
Width: 750mm-1300mm
AZ coating: 30g/m²-120 g/m²
Primer layer(base coat): 5-10um,
Fine coating layer(facade coat): 10-25um.
The types of paints: polyester(PE), silicon modified polyester(SMP),polyvinylidene fluoride(PVDF),epoxy resin.
Coil weight: 3-6mt
Coil inner diameter: 508mm or 610mm.
Base Material: Hot-dip galvalume steel

STANDARD&GRADE of prepainted galvalume steel coil :

ASTM A755M-03 EN10169-2003 JIS G 3322:2007
Commercial Quality CS DX51D+AZ CGLCC

RANGE OF APPLICATION of prepainted galvalume steel coil :

Box ,Containers, Furniture And Office Equipments , Transportation Industry, Structural engineering ,building and elextical and lighting equipments and etc.





Characteristics of prepainted gavalume steel coil :



Color Coated Steel Feature Excellent Decorativeness , Bendability , Corrosion Resistance, Coating Adhesion And Color Fastness .



They Are Ideal Substitutes For Wood Panels In The Construction Industry Because Of Their Good Economic Features Such As Convenient Installation , Conservation Of Energy And Resistance To Contamination .



Color Steel Sheets With Surface Texturing On The Surface Has Extremely Superb Anti - Scratch Qualities , Can Be Produced In Various Colors , And Has Credible Quality And Can Be Mass - Produced Economically.



Common roofing size based on prepainted galvalume steel coil as below:



Galvanized G550 Color Coated Prepainted galvalume steel coil For Roofing Transportation 0     Galvanized G550 Color Coated Prepainted galvalume steel coil For Roofing Transportation 1

Galvanized G550 Color Coated Prepainted galvalume steel coil For Roofing Transportation 2     Galvanized G550 Color Coated Prepainted galvalume steel coil For Roofing Transportation 3



Galvanized G550 Color Coated Prepainted galvalume steel coil For Roofing Transportation 4     Galvanized G550 Color Coated Prepainted galvalume steel coil For Roofing Transportation 5



Galvanized G550 Color Coated Prepainted galvalume steel coil For Roofing Transportation 6    Galvanized G550 Color Coated Prepainted galvalume steel coil For Roofing Transportation 7



Galvanized G550 Color Coated Prepainted galvalume steel coil For Roofing Transportation 8    Galvanized G550 Color Coated Prepainted galvalume steel coil For Roofing Transportation 9



Query:



1. How can you make sure your quality?

A:We have experienced inspector to check each order before production,if can not reach customer's

quirements,we won't export to our clients.



2. Hour about your experience?

A: We have exported steel products more than 6years, know all kinds of steel products very well.We can

always grasp the market and suggest our clients to order at the appropriate time.



3. How about your after-sales service?

A: We will give ourcustomer warranty according to the products requirements,if it is our quality issue in the warranty,we will help all customers to solve it until they are satisfied.





Here comes some common sizes of prepainted galvalume steel coil we export as below:





SHANGHAI HUIYI INTERNATIONAL CO.,LTD
Room 710,No.188,ChangYi Road,Baoshan District,Shanghai,China.
WOODEN PPGL EXPORTING SIZES
Size Zinc Coating Paint coating Color Paint Brand Application Export Countries
0.18x914 AZ30-AZ60 15-20um

white,red,blue,green,

grey,yellow,brown,ral colors and etc

Akzo nobel ,Nippon,Dulux,PPG,

wanbo,zhengniang,

wente and etc

Roofing metal,roller shutter doors,cold storage door cold bed,warehouse,factory, household electrical appliances and etc.

Singapore,Malaysia, Thailand,Brunei,

Dubai,

The Philippines, Ukraine

0.20x914 AZ30-AZ60 15-20um
0.22x914 AZ30-AZ60 15-20um
0.28x914 AZ30-AZ60 15-20um
0.30x914 AZ30-AZ60 15-20um
0.32x914 AZ30-AZ60 15-25um
0.36x914 AZ30-AZ60 15-25um
0.38x914 AZ60-AZ80 15-25um
0.40x914 AZ60-AZ80 15-25um
0.46x914 AZ60-AZ80 15-25um
0.47x914 AZ60-AZ80 15-25um
0.40x1220 AZ60-AZ150 20-30um
0.48x1220 AZ60-AZ150 20-30um
0.50x1220 AZ60-AZ150 20-30um
0.54x1220 AZ60-AZ150 20-30um
0.60x1220 AZ60-AZ150 20-30um
0.80x1220 AZ80-AZ150 20-30um
1.00x1220 AZ80-AZ150 20-30um
