SPCC SPCD Color Coated Roofing Sheets PPGL steel coi 680mm width

SPCC SPCD Color Coated Roofing Sheets PPGL steel coi 680mm width

Product Details:

Place of Origin: China
Brand Name: HUIYI
Certification: SGS,BV,ISO9001
Model Number: SPCC , SPCD , SPCE , DX51 / 52 / 53 / 54D + Z Q195 / 215 / 235 And etc

Payment & Shipping Terms:

Minimum Order Quantity: 25 tons each thickness
Price: negotiated
Packaging Details: Standard exporting package.wrapped with waterproof paper.Then high density PE film.Then after fully covered with iron sheet
Delivery Time: 20-35days
Payment Terms: L/C, T/T
Supply Ability: 50000 tons per year
Get Best Price Contact Now

Detail Information

Color: Red,Green,Blue,Grey,White,Brown,Black,Yellow,Maroon,Orange ,etc. Paint Brand: Akzo Nobel,Dulux,Nippon,PPG,Local
Front Paint Coating: 11-35um Back Paint Coating: 5-20um
AL-ZN Coating: AZ30-AZ150 Corrugated Width: 680mm Or Other Required Size
Thickness: 0.12--1.5mm Coil ID: 508/610mm
Surface Treatment: Coated, Galvanized, Printing ,galvalume Application: Roofing, Transportation, Building Construction, Boiler Plate
Standard: GB, ASTM, JIS, AISI, BS Name: Prepainted Color Steel Coil G550,G450,G400,G300
Highlight:

SPCD color coated roofing sheets

,

SPCC color coated steel plate

,

680mm color coated roofing sheets

Product Description

608mm Width Prepainted Color Steel Coil PPGL steel coil  CGLCC,CGLCH,G550,G450,G400,G300



PPGL steel coil introduction :



Generally, it refers to a product formed by coating (roll coating) a substrate after surface treatment or bonding an organic film and baking, which can be further processed into a final product. It’s called "pre-coated steel plate" and "plastic steel plate" in foreign countries. PPGL STEEL COIL  has beautiful colors or patterns when it leaves the factory, so it is also called "color coated steel plate". Color coated steel plate is commonly called in our country and is simply called "color coated plate" or "color plate".Color coated steel plate usually the galvanized steel,GL after surface treatment on their surfaces coated with a certain thickness of the adhesive coating or layer of organic film,after curing,become a color plate,with excellent corrosion resistance,molding,decoration in the building,home appliances,light industry,transportation and other industries widely used as an ideal composite material.



MAIN PARAMETERS OF PPGL STEEL COIL :



Thickness: 0.16mm-1.2mm
Width : 750mm-1300mm
AZ coating : 30g/m²-120 g/m²
Primer layer(base coat) : 5-10um,
Fine coating layer(facade coat) :10-25um.
The types of paints : polyester(PE), silicon modified polyester(SMP),polyvinylidene fluoride(PVDF),epoxy resin.
Coil weight : 3-6mt
Coil inner diameter : 508mm or 610mm.
Base Material : Hot-dip galvalume steel

STANDARD&GRADE OF PPGL STEEL COIL :

ASTM A755M-03 EN10169-2003 JIS G 3322:2007
Commercial Quality CS DX51D+AZ CGLCC

RANGE OF APPLICATION PPGL STEEL COIL :

Box ,Containers, Furniture And Office Equipments , Transportation Industry, Structural engineering ,building and elextical and lighting equipments and etc.





Characteristics of PPGL steel coil :



Color Coated Steel Feature Excellent Decorativeness , Bendability , Corrosion Resistance, Coating Adhesion And Color Fastness .



They Are Ideal Substitutes For Wood Panels In The Construction Industry Because Of Their Good Economic Features Such As Convenient Installation , Conservation Of Energy And Resistance To Contamination .



Color Steel Sheets With Surface Texturing On The Surface Has Extremely Superb Anti - Scratch Qualities , Can Be Produced In Various Colors , And Has Credible Quality And Can Be Mass - Produced Economically.



Common roofing size based on PPGL steel coil  as below:



SPCC SPCD Color Coated Roofing Sheets PPGL steel coi 680mm width 0     SPCC SPCD Color Coated Roofing Sheets PPGL steel coi 680mm width 1

SPCC SPCD Color Coated Roofing Sheets PPGL steel coi 680mm width 2     SPCC SPCD Color Coated Roofing Sheets PPGL steel coi 680mm width 3



SPCC SPCD Color Coated Roofing Sheets PPGL steel coi 680mm width 4     SPCC SPCD Color Coated Roofing Sheets PPGL steel coi 680mm width 5



SPCC SPCD Color Coated Roofing Sheets PPGL steel coi 680mm width 6    SPCC SPCD Color Coated Roofing Sheets PPGL steel coi 680mm width 7



SPCC SPCD Color Coated Roofing Sheets PPGL steel coi 680mm width 8    SPCC SPCD Color Coated Roofing Sheets PPGL steel coi 680mm width 9



Query:



1. How can you make sure your quality?

A: We have experienced inspector to check each order before production,if can not reach customer's

quirements,we won't export to our clients.



2. Hour about your experience?

A: We have exported steel products more than 6years, know all kinds of steel products very well.We can

always grasp the market and suggest our clients to order at the appropriate time.



3. How about your after-sales service?

A: We will give ourcustomer warranty according to the products requirements,if it is our quality issue in the warranty,we will help all customers to solve it until they are satisfied.





Here comes some common sizes of PPGL steel coil we export as below:





SHANGHAI HUIYI INTERNATIONAL CO.,LTD
Room 710,No.188,ChangYi Road,Baoshan District,Shanghai,China.
WOODEN PPGL EXPORTING SIZES
Size Zinc Coating Paint coating Color Paint Brand Application Export Countries
0.18x914 AZ30-AZ60 15-20um

white,red,blue,green,

grey,yellow,brown,ral colors and etc

Akzo nobel ,Nippon,Dulux,PPG,

wanbo,zhengniang,

wente and etc

Roofing metal,roller shutter doors,cold storage door cold bed,warehouse,factory, household electrical appliances and etc.

Singapore,Malaysia, Thailand,Brunei,

Dubai,

The Philippines, Ukraine

0.20x914 AZ30-AZ60 15-20um
0.22x914 AZ30-AZ60 15-20um
0.28x914 AZ30-AZ60 15-20um
0.30x914 AZ30-AZ60 15-20um
0.32x914 AZ30-AZ60 15-25um
0.36x914 AZ30-AZ60 15-25um
0.38x914 AZ60-AZ80 15-25um
0.40x914 AZ60-AZ80 15-25um
0.46x914 AZ60-AZ80 15-25um
0.47x914 AZ60-AZ80 15-25um
0.40x1220 AZ60-AZ150 20-30um
0.48x1220 AZ60-AZ150 20-30um
0.50x1220 AZ60-AZ150 20-30um
0.54x1220 AZ60-AZ150 20-30um
0.60x1220 AZ60-AZ150 20-30um
0.80x1220 AZ80-AZ150 20-30um
1.00x1220 AZ80-AZ150 20-30um
