GL Pre Painted Galvalume Sheets Minimised Spangle
Product Details:
| Place of Origin: | China |
| Brand Name: | HUYI-GL |
| Certification: | SGS , BV , ISO9001 |
| Model Number: | G550 , G450 , G300,DX51D+AZ,DX52D+AZ, SGLCC,SGLCH |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25tons each thickness |
|---|---|
| Price: | USD/MT |
| Packaging Details: | water proof paper & plastic film & protective steel sheet & protecting plate of inner & side panel & outside and inside diameter ring & metal band strapping & circumferential bands in steel |
| Delivery Time: | 15-35 days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 5000 tons per month |
|
Detail Information |
|||
| Product Name: | Perfoated GL/Metal /Punching 55% Galvalume Steel Coil , Minimised Spangle | Surface: | Minimise Spangle , Regular Spangle |
|---|---|---|---|
| Color: | Blue , White , Yellow , Red , Green Etc. | Width: | Under 600mm |
| Thickness: | 0.12mm-2.0mm | Zinc-coating: | AZ30-AZ150 |
| Standard: | ASTM , AISI , GB , JIS , DIN | Shape: | Coil / Flat /Corrugated |
| Coil ID: | 508mm/610mm | Surface Treatment: | Color AFP Or Non-AFP |
| Highlight: | HUYI GL pre painted galvalume sheets,HUYI AZ30 galvalume sheet roofing,600mm pre painted galvalume sheets |
||
Product Description
Perfoated GL/Metal /Punching 55% Galvalume Steel Coil , Minimised Spangle
Introduction:
Perfoated GL/Metal /Punching 55% Galvalume Steel Coil is a product produced by continuous hot-dip galvanizing process with cold-rolled steel coil as sbustrate . Aluminized zinc silicon steel sheet is an important alloy material frequently used in daily life. The aluminized zine silicon steel plate is a structure of aluminum zinc alloy. It is made up of 55% aluminum, 43.4% zinc and 1.6% silicon at 600 C. The whole structure is composed of aluminum, one iron, one silicon and one zinc, forming a compact four element crystal. Heat plated aluminum, zinc and silicon (GL) products, with various strength and thickness of the cold rolled steel plate as the base material, on the surface of the strip, heat plating aluminum (AL55%), zinc (ZN43.4%), silicon (S11.6%) alloy, have excellent corrosion resistance.Main usage of hot dip galvanized steel plate: Hot dip galvanized steel plate is mainly used in construction, automobiles, containers, transportation, household appliances and other fields, especially in steel structure construction, automobile manufacturing, steel plate manufacturing and other industries.
End products of Galvalume Steel Coil:
1. GL Corrugated sheet
2. GL Ceiling
3. GL Floor sheet...
4. Perforated sheet/coil
Application range:
Construction: the roof of the building, the exterior wall, the garage door, the fence, the shutter.
Home appliance industry: oven, air conditioning and ventilation system outside the cover, solar water heater, electrical components.
Automobile industry: automobile muffler, exhaust pipes and a catalytic converter heat shield, the bottom part of the car body, road signs.
Industrial instrumentation: electric control cabinet, industrial refrigeration cabinet, vending machine.
Specification:
| Products | 55% Clear Galvalume steel coil |
| Standard | ASTM A653 , JIS G3321 , GB/T3830-2006 |
| Grade | G550 , G450 , G300,DX51D+AZ,DX52D+AZ, SGLCC,SGLCH |
| Thickness | 0.12mm-2.0mm |
| Width | 30mm-1500mm |
| Base Metal | Cold Rolled Steel |
| AL-Zinc Coating | AZ30-150g/sqm |
| Coil Internal Diameter | 508mm/610mm |
| Surface Treatment | Chromating , Oiled |
| Tolerance | Thickness:+/-0.05mm , Width:+5/-2mm , Total Quantity:+/-10% , Zinc Coating:+/-10% |
| Surface Finish | Regular spangle ,Minimise spangle |
55% Galvalume Perforated Metal:
