1500mm Non AFP Galvalume Steel Sheet ASTM SGLCC

1500mm Non AFP Galvalume Steel Sheet ASTM SGLCC

Product Details:

Place of Origin: China
Brand Name: HUYI-GL
Certification: SGS , BV , ISO9001
Model Number: G550 , G450 , G300,DX51D+AZ,DX52D+AZ, SGLCC,SGLCH

Payment & Shipping Terms:

Minimum Order Quantity: 25tons each thickness
Price: USD/MT
Packaging Details: water proof paper & plastic film & protective steel sheet & protecting plate of inner & side panel & outside and inside diameter ring & metal band strapping & circumferential bands in steel
Delivery Time: 15-35 days
Payment Terms: L/C, D/P, T/T
Supply Ability: 5000 tons per month
Get Best Price Contact Now

Detail Information

Product Name: Non AFP Galvalume Steel / Color Coated 55% Galvalume Steel Coil AFP Width: 30mm-1500mm
Thickness: 0.12mm-2.0mm Color: White , Blue , Red , Green Etc.
Standard: ASTM , AISI , GB , JIS , DIN Shape: Coil / Flat /Corrugated
Inner Diameter: 508mm/610mm Surface Treatment: Color AFP Or Non-AFP
Highlight:

1500mm Galvalume Steel Sheet

,

HUYI Non AFP prepainted galvalume coil

,

HUYI SGLCC Galvalume Steel Sheet

Product Description

Anti-Finger Print , Non AFP Galvalume Steel / Color Coated 55% Galvalume Steel Coil AFP , Minimised Spangle



Introduction:



 The zinc layer has uniform thickness, strong adhesive force, no peeling during processing and molding, and good corrosion resistance.After passivation and oiling treatment, it will not deteriorate during short-term storage in the warehouse.With excellent cold rolled steel coil as  the substrate , it has excellent processing performance and good stamping resistance . Hot-dip aluzinc steel sheet is substrated on cold rolled steel(CRC)in various strength and specification Coating composition is 55%aIuminum in weight ratio.43 4%zinc.and 1 5%silicon with excellent corrosion and heat resistance performance.The surface is bright and clean , the size is accurate , the plate surface is straight , the zinc flower is even and beautiful . After its surface is finished , it is a good substrate for making anticorrosive coating plates .



Application range:



Construction industry  : air conditioning and ventilation system outside the cover , oven ,  electrical components , solar water heater .

Construction industry : the exterior wall , the roof of the building , the garage door, the fence, the shutter.

Industrial instrumentation: electric control cabinet, vending machine , industrial refrigeration cabinet .
Automobile industry: exhaust pipes and a catalytic converter heat shield , automobile muffler , the bottom part of the car body, road signs.





Products 55% Clear Galvalume steel coil
Standard ASTM A653 , JIS G3321 , GB/T3830-2006
Grade G550 , G450 , G300,DX51D+AZ,DX52D+AZ, SGLCC,SGLCH
Thickness 0.12mm-2.0mm
Width 30mm-1500mm
Base Metal Cold Rolled Steel
AL-Zinc Coating AZ30-150g/sqm
Coil Internal Diameter 508mm/610mm
Surface Treatment Chromating , Oiled
Tolerance Thickness:+/-0.05mm , Width:+5/-2mm , Total Quantity:+/-10% , Zinc Coating:+/-10%
Surface Finish Regular spangle ,Minimise spangle





Roofing sheets specification for  Galvalume steel coil :



1500mm Non AFP Galvalume Steel Sheet ASTM SGLCC 0         1500mm Non AFP Galvalume Steel Sheet ASTM SGLCC 1
