G300 Cold Rolled Precoated Galvalume Sheets Heat Resistance
Product Details:
| Place of Origin: | China |
| Brand Name: | HUYI-GI |
| Certification: | SGS , BV , ISO9001 |
| Model Number: | G550 , G450 , G300 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25tons each thickness |
|---|---|
| Price: | Negotiation |
| Packaging Details: | water proof paper & plastic film & protective steel sheet & protecting plate of inner & side panel & outside and inside diameter ring & metal band strapping & circumferential bands in steel |
| Delivery Time: | 15-35 days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 5000 tons per month |
|
Detail Information |
|||
| Product Name: | ISO9001 , G550 , G300 , Galvalume Steel Coil Cold Rolled For Building | Color: | Red , Blue . Yellow , White ,Orange , Brown . Etc. |
|---|---|---|---|
| Width: | 900mm-1250mm | Thickness: | 0.18mm-1.2mm |
| Zinc-coating: | Z20-Z600 | Standard: | ASTM , AISI , GB , JIS , DIN |
| Inner Diameter: | 508mm/610mm | Coil ID: | 508mm/610mm |
| Highlight: | Cold Rolled Precoated Galvalume Sheets,G300 Precoated Galvalume Sheets,Heat Resistance Precoated Galvalume Sheets |
||
Product Description
ISO9001 , G550 , G300 , Galvalume steel coil cold rolled for building
Galvalume steel sheet brief introduction:
The galvalume coating is an alloy consisting of approximately 55% aluminum, 43.4% zinc and 1.5% silicon by weight, which is applied to steel by the continuous hot dip process. Galvalume steel sheet offers the best qualities of aluminum coated (aluminized) and zinc coated steel sheet (galvanized). The aluminum/zinc coating has barrier corrosion resistance and heat resistance similar to aluminum coated steel. It also has good bare edge galvanic protection and forming qualities similar to continuously annealed commercial quality galvanized. The appearance of Galvalume coating is quite distinctive. Its smooth, flat and fine spangle and a silvery metallic appearance make it attractive in unpainted applications.
Galvalume steel sheet specifications:
| Products | Galvalume steel coil |
| Standard | ASTM A653 , JIS G3302 , GB/T3830-2006 |
| Grade | G550.G450,G300 |
| Thickness | 0.12mm-2.0mm |
| Width | 30mm-1500mm |
| Base Metal | Cold Rolled Steel |
| Zinc Coating | 20-600g/sqm |
| Coil Internal Diameter | 508mm/610mm |
| Surface Treatment | Chromatin , Oiled |
| Tolerance | Thickness:+/-0.05mm , Width:+5/-2mm , Total Quantity:+/-10% , Zinc Coating:+/-10% |
| Surface Finish | Regular spangle ,Minimise spangle |
