55% Non AFP AZ150  Galvalume Steel Sheet  610mm coil ID

55% Non AFP AZ150 Galvalume Steel Sheet 610mm coil ID

Product Details:

Place of Origin: China
Brand Name: HUYI-GL
Certification: SGS , BV , ISO9001
Model Number: G550 , G450 , G300,DX51D+AZ,DX52D+AZ, SGLCC,SGLCH

Payment & Shipping Terms:

Minimum Order Quantity: 25tons each thickness
Price: USD/MT
Packaging Details: water proof paper & plastic film & protective steel sheet & protecting plate of inner & side panel & outside and inside diameter ring & metal band strapping & circumferential bands in steel
Delivery Time: 15-35 days
Payment Terms: L/C, D/P, T/T
Supply Ability: 5000 tons per month
Get Best Price Contact Now

Detail Information

Product Name: Anti-Finger Print , Slitting 55% Galvalume Steel Coil AFP/ Non AFP /Slitting GL , Minimised Spangle Surface: Regular Spangle ,Minimise Spangle
Application: Decoration , Flange Plate , Ship Plate Width: Under 600mm
Thickness: 0.12mm-2.0mm Zinc-coating: AZ30-AZ150
Standard: ASTM , AISI , GB , JIS , DIN Shape: Coil / Flat /Corrugated
Coil ID: 508mm/610mm Surface Treatment: Color AFP Or Non-AFP
Highlight:

AZ150 galvalume Steel Sheet

,

Non AFP Galvalume Steel Sheet

,

Non AFP galvalume coil stock

Product Description

55% Galvalume Steel Sheet Non AFP AZ30-AZ150



Galvalume steel sheet introduction:



Galvalume Steel Coil is the idea alloy of aluminum and zinc . The surface is bright and clean ,the size is accurate ,the plate surface is straight , the zinc flower is even and beautiful . After its surface is finished , it is a good substrate for making anticorrosive coating plates .  55% aluminum, 43.4% zinc and 1.6% silicon at 600 C. The whole structure is composed of aluminum, one iron, one silicon and one zinc, forming a compact four element crystal. Heat resistance of the product is much better than ordinary galvaume steel coil , and almost equal to the Aluminum coil.





Galvalume Steel Coil Features:



Thermal Reflection:

People use it as material for heat-insulation for its thermal reflectivity as high as twice the galvanized steel sheet.

Heat-resistance:

The aluzinc steel sheet could bear above 300℃ high temperature with its good performance in heat-resistance, quite similar to the aluminized steel sheet’s performance in oxidation-resistance under high temperature. It is often used for chimney pipe, oven, illominator, and fluorescent lamp cover.

Corrosive-resistance performance:

The essential of galvalume steel coil’s corrosive-resistance lies at aluminium’s protective property. Once the zinc come under abrasion, the aluminium would form a layer of densified oxidized aluminium, preventing the interior from further corrosion.

Economical:

The density of 55%AL-Zn is smaller than Zn, therefore, with the same weight and thickness of coating, the galvalume steel sheet is 3% larger in area than that of galvanized steel sheet.

Easily painted:

There is perfect adhesiveness between galvalume sheet and paint, saving the process of pre-treatment and weathering for painting work.

The coating material on the galvalume steel sheet is outstanding in its adhesiveness, which could be directly tarring on the advertising board and commonly used board with no pre-treatment such as weathering process.

The galvalume steel sheet’s surface is luxury in silver colored appearance.
Galvalume steel sheet and galvanized steel sheet are similar in performance of processability and painting.



End products of Slitting Galvalume Steel sheet :



1. GL Corrugated sheet

2. GL Ceiling

3. GL Floor sheet...



Roofing sheets specification for Galvalume steel sheet  :



55% Non AFP AZ150  Galvalume Steel Sheet  610mm coil ID 0      55% Non AFP AZ150  Galvalume Steel Sheet  610mm coil ID 1





55% Non AFP AZ150  Galvalume Steel Sheet  610mm coil ID 2       55% Non AFP AZ150  Galvalume Steel Sheet  610mm coil ID 3



Application range of galvaluem steel sheet :



Construction : the roof of the building, the exterior wall, the garage door, the fence, the shutter.
Home appliance industry : oven, air conditioning and ventilation system outside the cover, solar water heater, electrical components.
Automobile industry : automobile muffler, exhaust pipes and a catalytic converter heat shield, the bottom part of the car body, road signs.
Industrial instrumentation : electric control cabinet, industrial refrigeration cabinet, vending machine.



Galvalume steel sheet specifications :



Products 55% Clear Galvalume steel sheet
Standard ASTM A653 , JIS G3321 , GB/T3830-2006
Grade G550 , G450 , G300,DX51D+AZ,DX52D+AZ, SGLCC,SGLCH
Thickness 0.12mm-2.0mm
Width 30mm-1500mm
Base Metal Cold Rolled Steel
AL-Zinc Coating AZ30-150g/sqm
Coil Internal Diameter 508mm/610mm
Surface Treatment Chromating , Oiled
Tolerance Thickness:+/-0.05mm , Width:+5/-2mm , Total Quantity:+/-10% , Zinc Coating:+/-10%
Surface Finish Regular spangle ,Minimise spangle
