DX52D+AZ Galvalume Steel Coil 0.12-2.0mm Thickness for Building Envelopes
Product Details:
| Place of Origin: | China |
| Brand Name: | Huiyi-GL |
| Certification: | ISO9001 |
| Model Number: | SGLCC,G550 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25Tons |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Exporting Packing with 3layers including the waterproof plastic film，Waterproof paper - plastic film-metal wrap. |
| Delivery Time: | 15-30 Days |
| Payment Terms: | L/C,D/P,T/T |
| Supply Ability: | 5000MT/Month |
|
Detail Information |
|||
| Product Type: | Coil / Sheet / Strip | Coating Content: | 55% Alu, 43.5% Zinc,1.5% Si |
|---|---|---|---|
| Thickness: | 0.12 - 2.0mm | Width: | 600 - 1500mm |
| Coating Weight: | 30-275g/㎡ | Coil Id: | 508mm/610mm |
| Surface Treatment: | Anti-Finger Printing, Chromated, Oiled, Non-Oiled | Payment Term: | T/T, L/C, D/P |
| Highlight: | DX52D+AZ Galvalume Steel Coil,55% Aluminum Coating Galvalume Steel Coil,0.12-2.0mm Thickness Galvalume Steel Coil |
||
Product Description
DX52D AZ80 Coating Galvalume Steel Coil with 55% Aluminum for Industrial
Product Description
Galvalume steel coils are produced through a hot-dip process with a coating composition of 55% aluminum, 43.5% zinc, and 1.5% silicon. This unique alloy delivers outstanding resistance to corrosion, acids, and humidity, along with excellent heat tolerance and paint adhesion. Its smooth, spangled surface and strong formability make it ideal for demanding architectural, industrial, and appliance applications.
Specification
| Product Name | Galvalume Steel Coil |
|---|---|
| Thickness | 0.12 - 2mm |
| Width | 600mm-1500mm |
| Alu-Zinc Coating | 30-275g/m² |
| Standards | ASTM A792, JIS G3321, EN 10346 |
| Spangle | Big / Medium / Small / Zero |
| Hardness | Soft , Hard, Full hard |
| Steel Grade | DX51D+AZ, DX52D+AZ, DX53D+AZ, S220GD-S550GD |
Applications
- Building Envelopes:
Selected for roofing, cladding, and structural components in residential, commercial, and industrial buildings where long-term weather resistance and low maintenance are critical. - HVAC Manufacturing:
Used in manufacturing external casings for air conditioners, ventilation units, and outdoor enclosures due to its corrosion resistance and durability in exposed environments. - Appliance Structural Parts:
Employed in internal frames, back panels, and support parts of refrigerators and other household appliances where strength, formability, and rust prevention are required. - Agricultural Buildings:
Specified for poultry houses, barns, storage facilities, and other farm structures where resistance to moisture, ammonia, and corrosive agricultural environments is essential.
Packing and Shipping
Our coils are protected by a triple-layer system including VCI anti-rust paper, PE waterproof film, and steel-strapped pallets with edge guards (capacity up to 8 tons each). We offer worldwide FOB/CIF shipping from China, with delivery in 15–20 days across Asia and 30–45 days to other global destinations.
FAQ
Q: How do I get a price quote?
A: Please send us your specific requirements, such as material, thickness, width, and quantity. Then we will provide you with our best quote accordingly.
Q: Can you arrange the shipment?
A: Yes, we have trusted freight forwarder who obtains the best available prices from various shipping companies and offers professional support.
Q: What are your payment terms?
A: We offer flexible terms, including:
1) 30% T/T deposit, with the balance payable against B/L copy;
2) 100% irrevocable L/C at sight.
Other arrangements can be discussed to suit your needs.
1) 30% T/T deposit, with the balance payable against B/L copy;
2) 100% irrevocable L/C at sight.
Other arrangements can be discussed to suit your needs.
