Regular Spangle Galvalume Steel Coil AZ30 Coating ID 508mm
Product Details:
| Place of Origin: | China |
| Brand Name: | HUYI-GL |
| Certification: | SGS , BV , ISO9001 |
| Model Number: | G550 , G450 , G300,DX51D+AZ,DX52D+AZ, SGLCC,SGLCH |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25tons each thickness |
|---|---|
| Price: | USD/MT |
| Packaging Details: | water proof paper & plastic film & protective steel sheet & protecting plate of inner & side panel & outside and inside diameter ring & metal band strapping & circumferential bands in steel |
| Delivery Time: | 15-35 days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 5000 tons per month |
|
Detail Information |
|||
| Product Name: | AISI 55% Galvalume Steel Coil AFP/ Non AFP | Surface: | Regular Spangle ，Minimise Spangle |
|---|---|---|---|
| Width: | 30mm-1500mm | Thickness: | 0.12mm-2.0mm |
| Zinc-coating: | AZ30-AZ150 | Standard: | ASTM , AISI , GB , JIS , DIN |
| Shape: | Coil / Flat /Corrugated | Coil ID: | 508mm/610mm |
| Surface Treatment: | Color AFP Or Non-AFP | Application: | Decoration , Flange Plate , Ship Plate |
| Highlight: | Regular Spangle Galvalume Steel Coil,AZ30 Coating Galvalume Steel Coil,ID 508mm Galvalume Steel Coil |
||
Product Description
AISI 55% Galvalume Steel Coil AFP/ Non AFP
Galvalume Steel Coil introduction:
Galvalume Steel Coil is also named as Aluzinc Steel Coil, this material is widely used in many fields such as building materials, home appliances, automobiles, environment, machinery, and ships. The surface of the material is covered with aluminum-zinc alloy, which is composed of 55% aluminum, 43.4% zinc and 1.6% silicon solidified at 600 °C. The whole structure is formed by aluminum-iron-silicon-zinc with a state of quaternary crystal.
Galvalume Steel Coil application range:
Construction: the roof of the building, the exterior wall, the garage door, the fence, the shutter.
Home appliance industry: oven, air conditioning and ventilation system outside the cover, solar water heater, electrical components.
Automobile industry: automobile muffler, exhaust pipes and a catalytic converter heat shield, the bottom part of the car body, road signs.
Industrial instrumentation: electric control cabinet, industrial refrigeration cabinet, vending machine.
Galvalume Steel Coil specifications :
| Products | 55% Clear Galvalume steel coil |
| Standard | ASTM A653 , JIS G3321 , GB/T3830-2006 |
| Grade | G550 , G450 , G300,DX51D+AZ,DX52D+AZ, SGLCC,SGLCH |
| Thickness | 0.12mm-2.0mm |
| Width | 30mm-1500mm |
| Base Metal | Cold Rolled Steel |
| AL-Zinc Coating | AZ30-150g/sqm |
| Coil Internal Diameter | 508mm/610mm |
| Surface Treatment | Chromating , Oiled |
| Tolerance | Thickness:+/-0.05mm , Width:+5/-2mm , Total Quantity:+/-10% , Zinc Coating:+/-10% |
| Surface Finish | Regular spangle ,Minimise spangle |
Roofing sheets specification for Galvalume steel coil :
