• AFP Aluminium Zinc Coated Steel Sheet DX51D+AZ Minimised Spangle
  • AFP Aluminium Zinc Coated Steel Sheet DX51D+AZ Minimised Spangle
  • AFP Aluminium Zinc Coated Steel Sheet DX51D+AZ Minimised Spangle
AFP Aluminium Zinc Coated Steel Sheet DX51D+AZ Minimised Spangle

AFP Aluminium Zinc Coated Steel Sheet DX51D+AZ Minimised Spangle

Product Details:

Place of Origin: China
Brand Name: HUYI-GL
Certification: SGS , BV , ISO9001
Model Number: G550 , G450 , G300,DX51D+AZ,DX52D+AZ, SGLCC,SGLCH

Payment & Shipping Terms:

Minimum Order Quantity: 25tons each thickness
Price: USD/MT
Packaging Details: water proof paper & plastic film & protective steel sheet & protecting plate of inner & side panel & outside and inside diameter ring & metal band strapping & circumferential bands in steel
Delivery Time: 15-35 days
Payment Terms: L/C, D/P, T/T
Supply Ability: 5000 tons per month
Get Best Price Contact Now

Detail Information

Product Name: Color Coated 55% Galvalume Steel Coil AFP/ Non AFP Galvalume Steel ,G550,G450,G300,Minimised Spangle,Anti-Finger Print Surface: Regular Spangle ,Minimise Spangle
Application: Decoration , Flange Plate , Ship Plate Width: 30mm-1500mm
Thickness: 0.12mm-2.0mm Zinc-coating: AZ30-AZ150
Standard: ASTM , AISI , GB , JIS , DIN Shape: Coil / Flat /Corrugated
Coil ID: 508mm/610mm Surface Treatment: Color AFP Or Non-AFP
Highlight:

AFP aluminium zinc coated steel sheet

,

HUYI-GL 2.0mm aluzinc steel coil

,

DX51D+AZ aluminium zinc coated steel sheet

Product Description

Color Coated 55% Galvalume Steel Coil AFP/ Non AFP Galvalume Steel ,G550,G450,G300,Minimised Spangle,Anti-Finger Print



Hot Dip Galvanizing Production Process:



Raw materials (cold rolled steel coils) → uncoiling → cutting head and tail → welding → spraying by alkali liquor→scrubbing by alkali liquor→ electrolytic degreasing → water scrubbing → hot air drying → entry looper → reduction and annealing → hot dip galvanizing → zinc layer control (air knife) → cooling → finishing → stretching, bending and straightening → purification → drying → exit looper → coil unloading → coil weighing → packaging → warehousing



Introduction:



Galvalume is a product very similar to Galvanized steel with better corrosion resistance(up to three times the life of galvanized steel ).The superior properties of Galvalume arise from the unique composition ( 43.5%Zn, 1.5% Si, 55% AL) of the metallic coating. Applications include roofing base material for pre-painting.Hot-dip aluzinc steel sheet is substrated on cold rolled steel(CRC)in various strength and specification Coating composition is 55%aIuminum in weight ratio.43 4%zinc.and 1 5%silicon with excellent corrosion and heat resistance performance.



Products : 55% Clear Galvalume steel coil

Standard : ASTM A653 , JIS G3321 , GB/T3830-2006

Grade : G550 , G450 , G300,DX51D+AZ,DX52D+AZ, SGLCC,SGLCH

Thickness : 0.12mm-2.0mm

Width : 30mm-1500mm

Base Metal : Cold Rolled Steel

AL-Zinc Coating : AZ30-150g/sqm

Coil Internal Diameter : 508mm/610mm

Surface Treatment : Chromating , Oiled

Tolerance : Thickness:+/-0.05mm , Width:+5/-2mm , Total Quantity:+/-10% , Zinc Coating:+/-10%

Surface Finish : Regular spangle ,Minimise spangle



Application range:



Construction: the roof of the building, the exterior wall, the garage door, the fence, the shutter.
Home appliance industry: oven, air conditioning and ventilation system outside the cover, solar water heater, electrical components.
Automobile industry: automobile muffler, exhaust pipes and a catalytic converter heat shield, the bottom part of the car body, road signs.
Industrial instrumentation: electric control cabinet, industrial refrigeration cabinet, vending machine.








Roofing sheets specification for  Galvalume steel coil :



AFP Aluminium Zinc Coated Steel Sheet DX51D+AZ Minimised Spangle 0         AFP Aluminium Zinc Coated Steel Sheet DX51D+AZ Minimised Spangle 1
