DX51D+AZ PVDF Coated PPGL Galvalume Steel Coil For Commercial Facades
Product Details:
| Place of Origin: | China |
| Brand Name: | Huiyi-PPGL |
| Certification: | EN 10346, ASTM A792, JIS G3322 |
| Model Number: | DX51D+AZ |
| Document: | HUIYI CATALOGUE.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25Tons |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Exporting Packing with 3layers including the waterproof plastic film，Waterproof paper - plastic film-metal wrap. |
| Delivery Time: | 15-30 Days |
| Payment Terms: | L/C,D/P,T/T |
| Supply Ability: | 5000MT/Month |
|
Detail Information |
|||
| Product Name: | Pre-painted Galvalume Steel Coil | Product Type: | Coil / Sheet / Strip |
|---|---|---|---|
| Coating Weight: | 100-150g/㎡ | Coil Weight: | 3 - 8 Tons |
| Thickness: | 0.30 - 2.0mm | Width: | 600mm - 1500mm |
| Coil ID: | 508mm/610mm | Surface Finish: | Smooth / Matte / Metallic / Textured |
| Highlight: | DX51D+AZ PVDF coated steel coil,PPGL Galvalume steel coil for facades,commercial facade PVDF coated steel |
||
Product Description
DX51D+AZ PVDF Coated PPGL Galvalume Steel Coil For Commercial Facades
Our DX51D+AZ PVDF Coated PPGL Galvalume Steel Coil is engineered as a premium architectural solution for commercial building facades requiring aesthetics, durability, and long-term performance. This advanced material combines a formable DX51D+AZ galvalume steel substrate with a high-performance PVDF (Polyvinylidene Fluoride) topcoat containing fluorocarbon resin with exceptional UV resistance. The PVDF coating provides outstanding protection against color fading, chalking, and sunlight degradation, with documented performance of 20+ years in exterior applications. The underlying AZ150 galvalume coating (55% aluminum, 43.4% zinc, 1.6% silicon) delivers 2-4 times better corrosion resistance than standard galvanized steel, ensuring substrate protection throughout the building's lifecycle.
Product Specifications
| Base Material | DX51D+AZ Galvalume Steel |
|---|---|
| Zinc Coating | AZ100 - AZ150 |
| Thickness | 0.30 - 2.0mm |
| Width | 600mm - 1500mm |
| Topcoat Type | PVDF (Polyvinylidene Fluoride) |
| Color Options | All RAL colors / Custom colors available |
| Paint System | Primer + Topcoat (double-coated, double-baked) |
| Key Performance | 20+ year exterior durability |
Applications
- Commercial Building Facades: Office towers, shopping centers, hotel exteriors requiring premium architectural finish
- Public & Institutional Buildings: Airports, high-speed rail stations, stadiums, convention centers, and museums
- Curtain Wall Systems: Metal panel cladding for modern curtain wall and rainscreen systems
- Architectural Cladding: Decorative wall panels, column covers, soffits, and fascia elements
Packaging and Shipping
Triple-Shield Packaging
VCI anti-rust kraft paper inner layer, 0.3mm PE waterproof film with moisture indicators, steel-strapped pallets + edge guards (max. 8-ton coils).
Global Logistics
FOB/CIF from Chinese ports; 15-20 day delivery for Asia, 30-45 days globally.
Quality Assurance
Pre-shipment inspection and moisture indicators for transit protection.
Frequently Asked Questions
Do you provide samples?
Yes, for regular sizes sample is free, buyer need to pay freight cost.
How can I get a quotation?
You can leave us message, and we will reply in time. And you can also find our contact details on the Contact page.
How long is the delivery time?
It depends on the order quantity, normally the delivery time takes around 15-30 working days. Please kindly contact us before ordering.
Want to Know more details about this product
