JIS G3302 Galvanized Steel Coil Hot Dipped GI Steel Coil For Building Appliance
Product Details:
| Place of Origin: | China |
| Brand Name: | HUIYI-GI |
| Certification: | SGS , BV , ISO9001 |
| Model Number: | DX51/52/53/54D+Z , Q195/21 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25tons each thickness |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Standard exporting package, wrapped with waterproof paper. Then high density PE film. after fully covered with iron sheet with metal edge protectors, strapped with metal bands |
| Delivery Time: | 15-35days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 8000 tons per month |
|
Detail Information |
|||
| Application: | Decoration , Flange Plate | Width: | Under 1600mm |
|---|---|---|---|
| Thickness: | 0.15-3.0mm | Zinc-coating: | Z20-Z275 |
| Standard: | ASTM , AISI , GB , JIS , DIN | Shape: | Coil/sheet |
| Coil ID: | 508mm/610mm | Surface: | Zero Spangle，chromated |
| Highlight: | Galvanized Steel Coil For Building Appliance,Hot Dipped Galvanized Steel Coil,JIS G3302 Galvanized Steel Coil |
||
Product Description
Galvanised steel coil introduction :
Galvanized steel is produced by continuously immersing cold-rolled steel coils in a molten zinc bath at around 470°C, forming a layer of zinc on the surface that provides effective corrosion resistance. This steel-based composite material significantly enhances durability and extends the service life of the product. It offers excellent corrosion resistance and high surface quality, making it suitable for deep processing. Economical and practical, galvanized steel is widely used in construction, household appliances, automotive manufacturing, container production, and the electromechanical industry.
Specifications of galvanised steel coil :
| Products | Galvanised Steel Coil/Sheet |
| Standard | ASTM A653 , JIS G3302 , GB/T3830-2006 |
| Grade | SPCC , SGCC , SGCD , DX51/52/53/54D+Z , Q195/215/235 And Etc |
| Thickness | 0.15-3.0mm |
| Width | 30-1600mm(Usual:914mm, 1219mm, 1229mm, 1250mm) |
| Base Metal | Cold Rolled Steel |
| Zinc Coating | 20-275g/sqm |
| Coil Internal Diameter | 508mm/610mm |
| Surface Treatment | Chromating , Oiled |
| Tolerance | Thickness tollerence:+/-0.03mm , width tollerence:+0/-5mm |
| Surface Finish | Big Spangle , Regualr Spangle , Minimized Spangle , Zero Spangle |
Galvanised steel coil Application:
1. Buildings and Constructions
Galvanized steel plays a crucial role in the building and construction industry due to its strength, durability, and resistance to corrosion. Common applications include floor decks, ceilings, ductwork, and roofing systems. It is widely used for wall siding, window sashes, structural beams, and fencing, providing long-term support with minimal maintenance. Outdoor elements such as verandas, shutters, and awnings benefit from its weather resistance. It is also utilized in partitions, interior decoration, piping systems, ventilators, storage sheds, and culverts, where both structural integrity and appearance are important.
2. Transportation
In the transportation sector, galvanized steel is favored for its ability to withstand harsh environmental conditions. It is commonly used in the production of vehicle body panels, air cleaner housings, oil and fuel filters, and fuel tanks. It also plays a role in the manufacture of shipping containers and highway safety barriers, where durability, impact resistance, and corrosion protection are essential for long service life.
3. Appliances
The home appliance industry makes extensive use of galvanized steel for its clean appearance and resistance to rust and wear. Applications include light fittings, washing machines, dryers, air coolers, and vending machines. It is also widely used in water heaters, cooking stoves, refrigerators, freezers, and tool boxes, where both functional performance and aesthetic appeal are important to consumers.
4. Agriculture
In agriculture, galvanized steel offers a cost-effective and weather-resistant solution for various structures and equipment. It is commonly used in the construction of barns, grain dryer panels, and animal housing facilities. Additional applications include hopper structures, bar supports, irrigation systems, and greenhouses, where reliable material performance is needed in challenging environmental conditions.
5. Others
Beyond industrial and commercial uses, galvanized steel is also utilized in a variety of general-purpose applications. These include furniture and office equipment, entertainment and vending machines, carports, and garden or storage sheds. Its versatility, ease of fabrication, and low maintenance needs make it an ideal choice for many residential and light-industrial products.
FAQ:
Q:Are you a trading company or a manufacturer?
A:We are one of the biggest and professional manufacturer in China. Our products are hot-sale due to our superior quality, competitive price and the best after-sales service.
Q:How about the MOQ?
A:Generally, the MOQ can be placed depending on different products.
Q:How about the sample if I need?
A:The sample is free of charge
Q:Do you have English Mill Test Certificates?
A:Yes, we can provide MTC attached to your documents.
Q:What is shipment terms?
A: 1. Container ship 2. Bulk ship 3. Train
Q:How about the delivery time?
A:About 10-25 days after receiving the deposit. Certainly, the detail will be confirmed by the quantity and the different products.
