JIS G3322 Color Coated Prepainted Galvanized Steel For Electronic Equipments
Product Details:
Place of Origin: | CHINA |
Brand Name: | PPGI---HUIYI |
Certification: | SGS,ISO,BV |
Model Number: | CGCC,CGLCC, CGCH , G550,G400,G450,DX51D |
Payment & Shipping Terms:
Minimum Order Quantity: | 25 tons |
---|---|
Price: | USD/MT |
Packaging Details: | Standard exporting package.wrapped with waterproof paper,high density PE film,iron sheet with metal edge protectors, strapped with metal bands, min 4 bands horizontal, min 3 bands vertical |
Delivery Time: | 20-35days |
Payment Terms: | L/C, D/P, T/T |
Supply Ability: | 5000 tons per month |
Detail Information |
|||
Product Name: | JIS G3322 Color Coated Coil For Electronic Equipments Etc. | Surface Treatment: | Coated,galvanised |
---|---|---|---|
Thickness: | 0.11-2.0mm | Width: | Under 1500mm |
Material: | GI,GL,SS Steel,Aluminium | Application: | Roofing ,decoration |
Coil ID: | 508MM,610MM | Coil Weight: | Based On Customers‘requirements |
Highlight: | Color Coated Prepainted Galvanized Steel,JIS G3322 Prepainted Galvanized Steel,Electronic Equipments Prepainted Galvanized Steel |
Product Description
JIS G3322 Color coated coil for electronic equipments etc.
Introduction:
PPGI Sheets are sheets of pre-painted or pre-coated Steel that display high durability, and resistance against weather and UV rays from sunlight. As such, they are widely used as roofing sheets for buildings and construction. They do not undergo corrosion owing to atmospheric conditions and can be easily installed through a simple technique. PPGI Sheets are abbreviated from Pre-Painted Galvanised Iron. These sheets exhibit high strength and resilience and almost never leak or corrode. They are usually available in attractive colours and designs per preference. The metallic coating on these sheets are usually of Zinc or Aluminium. The thickness of this paint coating is usually between 16-20 microns. Surprisingly, PPGI Steel Sheets are very light weight and easy to manoeuvre.
Standard : JIS G3312-1998 , ASTM A755 , GB / T12754 - 2006
Grade : Cold Rolled Steel / Galvanized Steel / Galvalume Steel
Base Metal : Cold Rolled Steel / Galvanized Steel / Galvalume Steel
Material Thickness : Normally 0.15 -1.5 mm
Width : 30 - 1500 mm ( Mainly in 914 mm ,1000 mm , 1219 mm and 1250 mm )
Coating : PE / PVDF / SMP
Coating Thickness : Min. Single Side - 50 g / sqm Max. Single Side - 275 g / sqm
Top Painting : 15 - 35 micrometer
Back Painting : 5 - 25 micrometer
Surface Finished Color : According To RAL Standard
Packing Condition : Seaworthy
Product Application of prepainted galvalume steel :
Buildings And Constructions | Workshop , Warehouse , Corrugated Roof And Wall , Rainwater , Drainage Pipe , Roller Shutter Door |
Electrical Appliance | Refrigerator , Washer , Switch Cabinet , Instrument Cabinet , Air Conditioning , Micro - wave Oven , Bread Maker |
Furniture | Central Heating Slice , Lampshade , Book Shelf |
Carrying Trade | Exterior Decoration Of Auto And Train , Clapboard , Container , Insulation Board |
Others | Writing Panel , Garbage Can , Billboard , Timekeeper , Typewriter , Instrument Panel , Weight Sensor , Photographic Equipment |
