1600mm GB/T 2518 Z600 DX51D Galvanised Steel Coil Cold Rolled
Product Details:
| Place of Origin: | China |
| Brand Name: | HUIYI-GI |
| Certification: | SGS , BV , ISO9001 |
| Model Number: | SPCC , SGCC , SGCH,SGCD , DX51/52/53/54D+Z , Q195/21 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25tons each thickness |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Standard exporting package, wrapped with waterproof paper. Then high density PE film. after fully covered with iron sheet with metal edge protectors, strapped with metal bands |
| Delivery Time: | 15-35days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 1000 tons per month |
|
Detail Information |
|||
| Product Name: | GB/T 2518 DX51/52/53/54D+Z , Q195/21 Standard Galvanised Steel Coil Cold Rolled | Application: | Decoration , Flange Plate , Ship Plate, Building |
|---|---|---|---|
| Width: | Under 1600mm | Thickness: | 0.11-3.0mm |
| Zinc-coating: | Z20-Z600 | Standard: | ASTM , AISI , GB , JIS , DIN |
| Shape: | Coil/sheet/corrugated/flat | Coil ID: | 508mm/610mm |
| Coil Weight: | According To Customers' Requirements | ||
| Highlight: | DX51D Galvanised Steel Coil,HUIYI 1600mm cold rolled steel coil,HUIYI Z600 Galvanised Steel Coil |
||
Product Description
GB/T 2518 DX51/52/53/54D+Z , Q195/21 Standard Galvanised Steel Coil Cold Rolled
It is made by taking hot galvanized sheet and zinc-iron alloy hot galvanized sheet as the substrate through surface pretreatment, coating one or more layers of liquid coating by roll coating, baking and cooling. The used coatings including polyester, silicon modified polyester, high-durability polyester, polyvinylidene fluoride, epoxy and high corrosion-resisting coating are widely used for building, transport, home appliances, solar energy, furniture, etc. It is mainly used as the side door plate of refrigerators, and shell of DVDs, air conditionings, freezers, and washing machines.Hot-dip aluzinc steel sheet is substrated on cold rolled steel(CRC)in various strength and specification Coating composition is 55％aIuminum in weight ratio．43 4％zinc．and 1 5％silicon with excellent corrosion and heat resistance performance.Hot-dip galvanized steel sheets (GI) are produced by passing the full hard sheet which has undergone the acid washing process and rolling process through the zinc pot, thereby applying zinc film to the surface. GI has a thicker galvanized layer which has excellent anti-corrosion qualities, and is the type of steel sheet used most commonly.
| SPECIES | GRADE | STANDARD | APPLICATION |
| PRESSING STEEL | DX51D+Z, | GB/T 2518 | common use,deep drawing |
| DX51D+ZF | |||
| DX52D+Z,DX52D+ZF | |||
| DX53D+Z,DX53D+ZF | |||
| DX54D+Z,DX54D+ZF | |||
| S220GD+Z,S220GD+ZF | |||
| CONSTRUCTION STEEL | S250GD+Z,S250GD+ZF | GB/T 2518 | construction material,corrosion resistance |
| S280GD+Z,S280GD+ZF | |||
| S320GD+Z,S320GD+ZF | |||
| S350GD+Z,S350GD+ZF | |||
| S400GD+Z,S400GD+ZF | |||
| S500GD+Z,S500GD+ZF | |||
| S550GD+Z,S550GD+ZF | |||
| HX260LAD+Z,HX260LAD+ZF | |||
| HX300LAD+Z,HX300LAD+ZF | |||
| HX340LAD+Z,HX340LAD+ZF | |||
| HX380LAD+Z,HX380LAD+ZF | |||
| HX420LAD+Z,HX420LAD+ZF | |||
| COLD ROLLED HIGH TENSILE STEEL | HC260/450DPD+Z,HC260/450DPD+ZF | GB/T 2518 | including alloy steel,corrosion resistance,good pressing |
| HC300/500DPD+Z,HC300/500DPD+ZF | |||
| HC340/600DPD+Z,HC340/600DPD+ZF | |||
| HC450/780DPD+Z,HC450/780DPD+ZF |
Q&A:
1. How to make sure your quality?
A: We have experienced inspector to check each order before production,if can not reach customer's quirements,we won't export to our clients.
2. Which contries does your company export to?
A: We have exported more than 20contries until now
Asia: Korea, Singapore, Vietnam, Thailand, Burma, India, Pakistan, Philippines,
Bangladesh, Nepal and Sri Lanka,Jordan, Israel, Saudi Arabia, Iraq, Iran,
Syria, Lebanon, UAE, Yemen
Europe: Romania, Turkey, Greece
Africa: Egypt, Algeria, Nigeria, Ghana, Sudan, Cameroon
Oceania: Australian
