Antibacterial Colour Coated Galvanized Sheets CGCC
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | PPGL--HUIYI |
| Certification: | SGS,BV,ISO |
| Model Number: | CGCC,CGCH,CGLCC,CGLCH，DX51D,DX52D |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25TONS |
|---|---|
| Price: | USD/MT |
| Packaging Details: | Standard exporting package. waterproof paper， high density PE film，iron sheet with metal edge protectors, strapped with metal bands |
| Delivery Time: | 20-35days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 5000 tons per month |
|
Detail Information |
|||
| Product Name: | Antibacterial Color Plate/Antibacterial PPGI /Antibacterial Prepainted Galvanised Steel Coil Sheet，CGCC,CGCH | Surface Treatment: | Coated , Galvalume |
|---|---|---|---|
| Width: | 600mm-1250mm, 750-1250m..... | Thickness: | 0.12-2.0mm |
| Grade: | SGCC, DX51D, DX51D+AZ, DX51D, CGLCCD | Standard: | GB, ASTM, JIS, AISI, BS |
| Zinc Coating: | Z20-Z275 | Coil ID: | 508mm/610mm |
| Highlight: | 914mm colour coated galvanized sheets,HUIYI 2mm metallic coated steel,CGCC colour coated galvanized sheets |
||
Product Description
Antibacterial color plate/Antibacterial PPGI /Antibacterial prepainted galvanised steel coil sheet,CGCC,CGCH
With GI as base metal,after pretreatment(degrease and chemical treatment)and liquid dope with several layers of color,then after firing and cooling,finally the plate steel is called pre-painted galvanized steel(PPGl).Pre-painted gaIvanized steeI is good capable of decoration,molding,corrosion resistance.
Thickness : 0.3mm-1.0mm(BMT)
Width : 914mm-1250mm
Paint Brand : AKZO , NIPPON ,PPG , DULLEX ,PE OR PVDF
Color : RAL Scale ,or based on customers‘samples
Coil ID : 508MM / 610MM
Zinc Coating : Z20-Z275
Grade : CGCC,CGCH,G550,G450,G400,G300
Front Paint Coating : 15 -35um
Back Paint Coating : 5-20um
Introduction:
The product uses metal ion dissolution of the antibacterial mechanism, in the course of antibacterial agent slowly release metal ions, dissolution of metal ions that can destroy the bacterial cell membrane or cell protoplasm activity of enzyme activity, also has anti-yellow staphylococcus and Escherichia coli Of the role, with high antibacterial efficiency, antibacterial time is long and so on. Antibacterial color plate on Staphylococcus aureus, Escherichia coli and other Gram-negative bacteria rate of 99% or more, the growth of fungi and fungi also significantly inhibited, is to reduce cross-infection and bacterial infection probability of an effective way , Has broad market prospects and huge application potential.
Such kind of product is mainly used in hospital walls, ceilings, food storage and processing areas, ventilation systems and other facilities, with excellent antibacterial and processing performance.
Here comes some roofing sheets specification:
