Fiberglass Wool Thermal Insulation Pipe Construction Material
Product Details:
| Place of Origin: | China |
| Brand Name: | HUIYI |
| Certification: | CE,ISO ,BV,A1,AS/NZ |
| Model Number: | SHHY |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Container |
|---|---|
| Price: | Negotiation |
| Packaging Details: | water proof paper & plastic film & protective steel sheet & protecting plate of inner & side panel & outside and inside diameter ring & metal band strapping & circumferential bands in steel |
| Delivery Time: | 15-35days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 5000 tons per month |
|
Detail Information |
|||
| Product Name: | Glass Wool Pipe | Application: | Glass Wool Pipe, Thermal Insulation |
|---|---|---|---|
| Design Style: | Fiberglass Wool Pipe | Thermal Conductivity:: | 0.030-0.044 |
| Diameter: | 22-610mm | Density: | 48-80kg/m3 |
| Thickness: | 25-100mm Glass Wool | Color: | Yellow |
| Highlight: | Fiberglass Wool Insulation Tube,Glass Wool Thermal Insulation Pipe,25mm Construction Thermal Insulation Pipe |
||
Product Description
Fiberglass Wool Tube Construction Material Glass Wool Thermal Insulation Pipe
The glass wool product is placed in the glass of meltdown appearance proceed the fiber turn and spray the resin of solid that draw the hot silk wadding form material, then turn through hot solid the deep processing handles and can also make into the series and various products.
HUIYI glass wool felt is divided into bare felt and veneer rolled felt, which can effectively resist moisture, sound absorption, corrosion, and aesthetics. The surface layer is added to increase the product's breaking resistance, breakdown resistance, high tensile strength, beautiful appearance and simple construction.
|
Item Name
|
Specification
|
Unit
|
|
Factor of heat conduction(Temperature 25°C)
|
≤0.034
|
W/mk
|
|
Combustion performance
|
non-inflammable,A1
|
-
|
|
Organic content
|
≤5
|
%
|
|
Hydrophobic coefficient
|
≥98
|
%
|
|
Reshrinking temperature
|
≥350
|
℃
|
|
Formaldehyde emission
|
≤1.5
|
mg/L
|
|
Water absorption coefficient
|
≤1.5
|
%
|
|
Water content
|
≤1.0
|
%
|
|
Slag wall content(dia>0.25mm)
|
≤0.3
|
%
|
|
Average diameter of fiber
|
≤8.0
|
μm
|
|
Odor emission
|
no
|
-
|
|
Asbestos
|
asbestos free
|
-
|
| Pipe O/D mm |
Tube Wall Thickness (mm) | |||||||||||
| 21-610 | 20 | 25 | 30 | 35 | 40 | 50 | 60 | 70 | 80 | 90 | 100 | |
| Length 1 linear metre |
20 | 25 | 30 | 35 | 40 | 50 | 60 | 70 | 80 | 90 | 100 | |
Advantages of Fiberglass wool insulation :
- Fireproof
- Waterproof
- Lightweight
- Eco-friendly
- Easy to install
- Heat insulation
- Thermal insulation
- Soundproof
Package and Delivery of Fiberglass wool insulation :
FAQ:
Q: Can you accept neutral packing & OEM ?
A: Normally, our packing is carton , but we can accept the neutral packing and OEM.
Q: Can you provide the sample for free ?
A: We provide some samples for free.
Q: What's the lead time?
A: 15-35 days after receipt of advanced payment
Q: What's the payment term?
A: 30% advanced payment and 70% paid prior to load by TT. and large amount can be paid by LC.
