Product Details:

Place of Origin: China
Brand Name: HUYI-GL
Certification: SGS , BV , ISO9001
Model Number: G550 , G450 , G300,DX51D+AZ,DX52D+AZ, SGLCC,SGLCH

Payment & Shipping Terms:

Minimum Order Quantity: 25tons each thickness
Price: USD/MT
Packaging Details: water proof paper & plastic film & protective steel sheet & protecting plate of inner & side panel & outside and inside diameter ring & metal band strapping & circumferential bands in steel
Delivery Time: 15-35 days
Payment Terms: L/C , D/P , T/T
Supply Ability: 5000 tons per month
Get Best Price Contact Now

Detail Information

Product Name: Color Coated 55% Galvalume Steel Coil AFP/ Non AFP Galvalume Steel , Minimised Spangle , Anti-Finger Print Surface: Regular Spangle ,Minimise Spangle
Application: Decoration , Flange Plate , Ship Plate Width: 30mm-1500mm
Thickness: 0.12mm-2.0mm Zinc-coating: AZ30-AZ150
Standard: ASTM , AISI , GB , JIS , DIN Shape: Coil / Flat /Corrugated
Coil ID: 508mm/610mm Surface Treatment: Color AFP Or Non-AFP
Highlight:

Color AFP Galvalume Profile Sheet

,

HUYI G300 Galvalume Steel Coil

,

HUYI AZ150 Galvalume Profile Sheet

Product Description

Color Coated 55% Galvalume Steel Coil AFP/ Non AFP Galvalume Steel , Minimised Spangle , Anti-Finger Print



Introduction:



Galvalume is a product which is very similar to Galvanized steel but with better corrosion resistance(up to 3 times life of galvanized).The supperior properties of galvalume arise from the unique composition(43.5%Zn,1.5%Si,55%AL) of the metallic coating.The galvalume steel coil has uniform thickness ,strong adhesive force , no peeling during processing and molding , and good corrosion resistance.The surface is bright and clean , the size is accurate ,the coil surface ia straight ,the zinc flower is even and beautiful .After its surface is finished ,it is a good substrate for making anticorrosive coating coil. Hot-dip aluzinc steel sheet is substrated on cold rolled steel(CRC)in various strength and specification Coating composition is 55%aIuminum in weight ratio.43 4%zinc.and 1 5%silicon with excellent corrosion and heat resistance performance.



Application range:



Construction: the roof of the building, the exterior wall, the garage door, the fence, the shutter.
Home appliance industry: oven, air conditioning and ventilation system outside the cover, solar water heater, electrical components.
Automobile industry: automobile muffler, exhaust pipes and a catalytic converter heat shield, the bottom part of the car body, road signs.
Industrial instrumentation: electric control cabinet, industrial refrigeration cabinet, vending machine.





Products 55% Clear Galvalume steel coil
Standard ASTM A653 , JIS G3321 , GB/T3830-2006
Grade G550 , G450 , G300,DX51D+AZ,DX52D+AZ, SGLCC,SGLCH
Thickness 0.12mm-2.0mm
Width 30mm-1500mm
Base Metal Cold Rolled Steel
AL-Zinc Coating AZ30-150g/sqm
Coil Internal Diameter 508mm/610mm
Surface Treatment Chromating , Oiled
Tolerance Thickness:+/-0.05mm , Width:+5/-2mm , Total Quantity:+/-10% , Zinc Coating:+/-10%
Surface Finish Regular spangle ,Minimise spangle





Roofing sheets specification for  Galvalume steel coil :



Decoration Color AFP Galvalume Profile Sheet AZ150 0         Decoration Color AFP Galvalume Profile Sheet AZ150 1
