1220mm Hot Dip Galvanized Steel Plate Hard Sheet
Product Details:
| Place of Origin: | China |
| Brand Name: | HUIYI-GI |
| Certification: | SGS,BV,ISO9001 |
| Model Number: | SPCC,SGCC,SGCD,DX51/52/53/54D+Z,Q195/215/235 And Etc |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25tons each thickness |
|---|---|
| Price: | USD/MT |
| Packaging Details: | Standard exporting package.wrapped with waterproof paper.Then after fully wrapped with high density PE film. Then after fully covered with iron sheet with metal edge protectors, strapped with metal bands, min 4 bands horizontal, min 3 bands vertical. |
| Delivery Time: | 15-35days |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | 20000 tons per month |
|
Detail Information |
|||
| Product Name: | Hot-dip Galvanized Steel Sheet,Hard Sheet,Galvanized Steel Coil | Application: | Decoration, Flange Plate, Ship Plate, |
|---|---|---|---|
| Width: | Under 1600mm | Thickness: | 0.11-6.0mm |
| Zinc-coating: | Z20-Z600 | Standard: | ASTM, AISI, GB, JIS, DIN |
| Shape: | Coil/sheet | Coil ID: | 508mm/610mm |
| Highlight: | HUIYI 1220mm hot dip galvanized steel plate,HUIYI 1220mm galvanised steel panel,SPCC hot dip galvanized steel plate |
||
Product Description
Hot-dip Galvanized Steel Sheet,Hard Sheet,Galvanized Steel Coil
As a new product of huiyi , Galvalume (abbreviation:GL steel) is hot plating on the surface of steel plate with Al55%,Zn43.5%,Si l.5% ,the surface is smooth,has a good rsistance to atmospheric corrosion,heat resistant oxidation.Hot galvanized sheet and alloying galvanized sheet have excellent performance, ideal combination property including corrosion resistance, formation and coating, and are mainly used for building, automobiles, metallurgy, and electrical equipment. Galvanized sheet is mainly used for making roof, door and window, roller shutter door, and suspended skeleton in building industry, vehicle shell, chassis, door, trunk lid, oil tank and fender in auto industry, steel sash blank and color coated sheet substrate in metallurgy industry, and refrigerator base, shell, refrigerating chamber, kitchen equipment and other parts in electrical equipment industry.Hot-dip galvanized steel sheets (GI) are produced by passing the full hard sheet which has undergone the acid washing process and rolling process through the zinc pot, thereby applying zinc film to the surface. GI has a thicker galvanized layer which has excellent anti-corrosion qualities, and is the type of steel sheet used most commonly.
Specifications
■ Standard : ASTM A653,JIS G3302,GB/T3830-2006
■ Grade : SPCC,SGCC,SGCD,DX51/52/53/54D+Z,Q195/215/235 And Etc
■ Thickness : 0.11-6.0mm
■ Width : 30-1600mm(Usual:914mm,1219mm,1220mm,1250mm)
■ Base Metal : Cold-Rolled Steel
■ Zinc Coating : 20-600g/sqm
■ Coil Internal Diameter : 508mm/610mm
■ Surface Treatment : Chromating,Oiled
■ Tolerance: Thickness :+/-0.05mm,Width:+5/-2mm,Total Quantity:+/-10%,Zinc Coating:+/-10%
■ Surface Finish : Big Spangle,Regular Spangle,Minimized Spangle,Zero Spangle
