Cold Rolled Chromating Electro Galvanized Sheet Metal 1229mm

Cold Rolled Chromating Electro Galvanized Sheet Metal 1229mm

Product Details:

Place of Origin: China
Brand Name: HUIYI-GI
Certification: SGS , BV , ISO9001
Model Number: SPCC , SGCC , SGCD , DX51/52/53/54D+Z , Q195/21

Payment & Shipping Terms:

Minimum Order Quantity: 25tons each thickness
Price: Negotiation
Packaging Details: Standard exporting package, wrapped with waterproof paper. Then after fully wrapped with high density PE film. Then after fully covered with iron sheet with metal edge protectors, strapped with metal bands, min 4 bands horizontal, min 3 bands vertical.
Delivery Time: 15-35days
Payment Terms: L/C, D/P, T/T
Supply Ability: 5000 tons per month
Get Best Price Contact Now

Detail Information

Product Name: Zero Spangle Galvanised Steel Coil Cold Rolled/Hot Dipped Surface: Big Spangle , Regular Spangle , Minimized Spangle
Shape: Coil/sheet Width: Under 1600mm
Thickness: 0.11-6.0mm Zinc-coating: Z20-Z600
Standard: ASTM , AISI , GB , JIS , DIN Coil ID: 508mm/610mm
Highlight:

6mm electro galvanized sheet metal

,

Z600 electrogalvanized steel sheet

,

1229mm electro galvanized sheet metal

Product Description

Zero Spangle Galvanised Steel Coil Cold Rolled/Hot Dipped



Galvanized steel sheet is mainly used in construction, light industry, automobile, agriculture, animal husbandry, fishery and business. The construction industry is mainly used in the manufacture of anticorrosive industrial and civil building roof panels, roof grille, etc.; the light industry industry uses its home appliance shell, civil tobacco meat, kitchen utensils, etc., the automobile industry is mainly used for the corrosion resistant parts of cars, and so on; the farmers and animal husbandry ownersIt should be used for grain storage and transportation, frozen processing equipment for meat and aquatic products, etc.Hot-dip galvanized steel sheets (GI) are produced by passing the full hard sheet which has undergone the acid washing process and rolling process through the zinc pot, thereby applying zinc film to the surface. GI has a thicker galvanized layer which has excellent anti-corrosion qualities, and is the type of steel sheet used most commonly.





Products Galvanised Steel Coil/Sheet
Standard ASTM A653 , JIS G3302 , GB/T3830-2006
Grade SPCC , SGCC , SGCD , DX51/52/53/54D+Z , Q195/215/235 And Etc
Thickness 0.11-6.0mm
Width 30-1600mm(Usual:914mm, 1219mm, 1229mm, 1250mm)
Base Metal Cold Rolled Steel
Zinc Coating 20-600g/sqm
Coil Internal Diameter 508mm/610mm
Surface Treatment Chromating , Oiled
Tolerance Thickness:+/-0.05mm , Width:+5/-2mm , Total Quantity:+/-10% , Zinc Coating:+/-10%
Surface Finish Big Spangle , Regualr Spangle , Minimized Spangle , Zero Spangle



Product Application



1. Buildings And Constructions



    Floor Decks, Ceilings, Duct Work, Roofing, Siding, Sashes, Beams, Fences, Verandas, Shutters, Awnings,



 Partitions, Indoor Decorations, Pipes, Ventilators, Sheds, Culverts.



2. Transportation



    Body Pane, Air Cleaners, Oil Filters, Fuel Tanks, Containers, Highway Barriers.



3. Appliances



    Light Fittings, Washing Machines, Dryers, Coolers, Vending Machines, Water Heaters, Stoves, Refrigerators, Freezers, Tool Boxes.



4. Agriculture



   Barns, Dryer Panels, Animal Houses, Hoppers. Bar Supporters, Irrigation Systems, Green Houses.



5. Others



    Furniture And Office Equipment, Entertainment Machines, Car Ports, Garden And Storage Sheds
