1219mm JIS G3302 Zero Spangle Galvanized Steel Roof Panel SGCH

1219mm JIS G3302 Zero Spangle Galvanized Steel Roof Panel SGCH

Product Details:

Place of Origin: China
Brand Name: HUIYI-GI
Certification: SGS , BV , ISO9001
Model Number: SPCC , SGCC , SGCH,SGCD , DX51/52/53/54D+Z , Q195/21

Payment & Shipping Terms:

Minimum Order Quantity: 25tons each thickness
Price: Negotiation
Packaging Details: Standard exporting package, wrapped with waterproof paper. Then high density PE film. after fully covered with iron sheet with metal edge protectors, strapped with metal bands
Delivery Time: 15-35days
Payment Terms: L/C, D/P, T/T
Supply Ability: 8000 tons per month
Get Best Price Contact Now

Detail Information

Product Name: JIS G3302 Standard Zero Spangle Galvanised Steel Coil Cold Rolled/Hot Dipped,G550,G450,G400,SGCC,SGCH Surface: Zero Spangle,chromated,unoiled
Application: Decoration , Flange Plate , Ship Plate, Building Width: Under 1600mm
Thickness: 0.11-6.0mm Zinc-coating: Z20-Z600
Standard: ASTM , AISI , GB , JIS , DIN Shape: Coil/sheet
Coil ID: 508mm/610mm
Highlight:

JIS G3302 galvanized steel roof panel

,

SGCH galvanized steel roof panel

,

1219mm galvanized steel roof panel

Product Description

JIS G3302 Standard Zero Spangle Galvanised Steel Coil Cold Rolled/Hot Dipped,G550,G450,G400,SGCC,SGCH

Galvanized Steel Coils are produced through a process of metal coating which involves passing cold rolled coils through a kettle containing molten zinc. This process ensures adhesion of Zinc to the surface of the steel sheet. The Zinc Layer provides excellent corrosion resistance and prolong service life. Hot dip galvanized products are widely used in household appliances, transport, container manufacturing, roofing, base material for pre-painting, ducting and other construction related applications . Hot-dip galvanized steel sheets (GI) are produced by passing the full hard sheet which has undergone the acid washing process and rolling process through the zinc pot, thereby applying zinc film to the surface. GI has a thicker galvanized layer which has excellent anti-corrosion qualities, and is the type of steel sheet used most commonly.



Products Galvanised Steel Coil/Sheet
Standard ASTM A653 , JIS G3302 , GB/T3830-2006
Grade SPCC , SGCC , SGCD , DX51/52/53/54D+Z , Q195/215/235 And Etc
Thickness 0.11-6.0mm
Width 30-1600mm(Usual:914mm, 1219mm, 1229mm, 1250mm)
Base Metal Cold Rolled Steel
Zinc Coating 20-600g/sqm
Coil Internal Diameter 508mm/610mm
Surface Treatment Chromating , Oiled
Tolerance Thickness:+/-0.05mm , Width:+5/-2mm , Total Quantity:+/-10% , Zinc Coating:+/-10%
Surface Finish Big Spangle , Regualr Spangle , Minimized Spangle , Zero Spangle



Product Application



1. Buildings And Constructions



    Floor Decks, Ceilings, Duct Work, Roofing, Siding, Sashes, Beams, Fences, Verandas, Shutters, Awnings,



 Partitions, Indoor Decorations, Pipes, Ventilators, Sheds, Culverts.



2. Transportation



    Body Pane, Air Cleaners, Oil Filters, Fuel Tanks, Containers, Highway Barriers.



3. Appliances



    Light Fittings, Washing Machines, Dryers, Coolers, Vending Machines, Water Heaters, Stoves, Refrigerators, Freezers, Tool Boxes.



4. Agriculture



   Barns, Dryer Panels, Animal Houses, Hoppers. Bar Supporters, Irrigation Systems, Green Houses.



5. Others



    Furniture And Office Equipment, Entertainment Machines, Car Ports, Garden And Storage Sheds
